Product Description
Engineered for relentless performance, this 2022 Sany SY870H excavator delivers proven reliability in the 87-ton class. With just minimal operating hours since manufacture, this backhoe-configured machine demonstrates Sany's commitment to industrial-grade durability. Powered by a robust 377kW engine at 1800 rpm, it generates exceptional bucket digging force of 432/469 kN and rod digging force of 370/402 kN—figures that translate directly to productivity on demanding job sites.
Built to handle the toughest applications, this workhorse offers:
- Maximum digging reach of 11,703mm with 7,247mm digging depth
- Generous 5.0-6.5m³ bucket capacity for high-volume material handling
- 70% climbing ability and 880mm ground clearance for challenging terrain
- 4,770mm track ground length ensuring superior stability under load
- Operational track gauge of 3,380mm for enhanced balance during heavy excavation
Currently located in Hangzhou, Zhejiang, this Chinese-manufactured excavator represents solid value backed by Sany's engineering standards. Its low-hour status confirms the quality construction that defines modern heavy equipment investments.
| Specifications | Value |
|---|---|
| No. | 1028458 |
| Tonnage (tons) | 87 |
| Working weight (kg) | 78600 |
| Bucket capacity (m³) | 5.0-6.5 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 377/1800 |
| Ground specific pressure (Kpa) | 114 |
| Rotation speed (rpm) | 7.7 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 432/469 |
| Rod digging force (kN) | 370/402 |
| Travel speed (km/h) | 4.5/2.9 |
| Total transport length (mm) | 13002 |
| Total transport width (mm) | 4320 |
| Total transport height (mm) | 4742 |
| Full cab height (mm) | 3795 |
| Minimum ground clearance (mm) | 880 |
| Minimum turning radius of front working device (mm) | 5586 |
| Back end turning radius (mm) | 4220 |
| Onboard width (mm) | 3460 |
| Total track length (mm) | 5946 |
| Track gauge (mm) | 3380 (Operation) /2780 (Transportation) |
| Track plate width (mm) | 650 |
| Track ground length (mm) | 4770 |
| Maximum height at minimum turning radius (mm) | 9802 |
| Maximum digging radius (mm) | 11703 |
| Maximum digging depth (mm) | 7247 |
| Maximum excavation height (mm) | 10910 |
| Maximum unloading height (mm) | 7047 |
| Maximum vertical digging depth (mm) | 6792 |
