Product Description
Secure an 87-ton hydraulic excavator without the factory wait. This 2022 Sany SY870H is ready for immediate dispatch from Wenzhou, Zhejiang—cutting weeks or months from your project timeline. Powered by a robust 377 kW engine and equipped with a 5.0-6.5 m³ backhoe bucket, this machine delivers 432 kN bucket digging force and reaches a maximum digging depth of 7,247 mm. Built for large-scale earthmoving, quarrying, and infrastructure projects where downtime costs you revenue.
- Operating Weight: 78,600 kg
- Rated Power: 377 kW @ 1,800 rpm
- Maximum Digging Reach: 11,703 mm
- Bucket Capacity: 5.0-6.5 m³
- Track Gauge: 3,380 mm (operation) / 2,780 mm (transport)
- Location: Wenzhou, Zhejiang—available now
Skip factory lead times and deploy heavy lifting capacity to your site within days. Inspections arranged upon request. Contact Fair Trade Machinery today for fast-track logistics and competitive export terms.
| Specifications | Value |
|---|---|
| No. | 1029209 |
| Tonnage (tons) | 87 |
| Working weight (kg) | 78600 |
| Bucket capacity (m³) | 5.0-6.5 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 377/1800 |
| Ground specific pressure (Kpa) | 114 |
| Rotation speed (rpm) | 7.7 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 432/469 |
| Rod digging force (kN) | 370/402 |
| Travel speed (km/h) | 4.5/2.9 |
| Total transport length (mm) | 13002 |
| Total transport width (mm) | 4320 |
| Total transport height (mm) | 4742 |
| Full cab height (mm) | 3795 |
| Minimum ground clearance (mm) | 880 |
| Minimum turning radius of front working device (mm) | 5586 |
| Back end turning radius (mm) | 4220 |
| Onboard width (mm) | 3460 |
| Total track length (mm) | 5946 |
| Track gauge (mm) | 3380 (Operation) /2780 (Transportation) |
| Track plate width (mm) | 650 |
| Track ground length (mm) | 4770 |
| Maximum height at minimum turning radius (mm) | 9802 |
| Maximum digging radius (mm) | 11703 |
| Maximum digging depth (mm) | 7247 |
| Maximum excavation height (mm) | 10910 |
| Maximum unloading height (mm) | 7047 |
| Maximum vertical digging depth (mm) | 6792 |
