Product Description
Strengthen your fleet with this 2017 SDLG L953 wheel loader, currently available in Baoding, Hebei. Built for contractors who demand consistent uptime, this 5-ton capacity machine delivers reliable performance across material handling, loading, and site preparation tasks. Powered by a WP10G220E341 engine producing 162 kW at 2200 rpm with 950 N·m of maximum torque, this loader combines proven mechanical strength with operational efficiency that keeps job sites moving.
- Rated load capacity: 5,000 kg with 175 kN digging force
- Operating weight: 16,800 kg for stable material handling
- Maximum unloading height: 3,080 mm; unloading distance: 1,105 mm
- Top speed: 38 km/h with 152 kN maximum tractive force
- Fuel capacity: 260 L for extended shift operation
- Compact dimensions: 7,920 mm (L) × 3,024 mm (W) × 3,423 mm (H)
With 35-degree steering articulation and a 534 mm ground clearance, this L953 navigates congested sites and uneven terrain without hesitation. Perfect as a secondary unit or fleet expansion, it provides the redundancy busy contractors need when primary equipment is deployed elsewhere.
| Specifications | Value |
|---|---|
| No. | 1020067 |
| Engine type | WP10G220E341 |
| Rated power (kw/rpm) | 162/2200 |
| Cooling mode | |
| Maximum torque (N.m) | 950 |
| Working form | |
| Exhaust volume (L) | 9.726 |
| Bucket capacity (m³) | |
| Rated load (tons) | |
| Rated load (kg) | 5000 |
| Digging force (lifting force) (kN) | 175 |
| Machine operating weight (kg) | 16800 |
| Max - Unloading height (mm) | 3080 |
| Unloading distance (mm) | 1105 |
| Maximum tractive force (kN) | 152 |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 240 |
| Engine Oil (L) | 20 |
| Wheelbase (mm) | 3000 |
| Wheel base (mm) | 2250 |
| Minimum ground clearance (mm) | 534 |
| Machine length (mm) | 7920 |
| Machine width (mm) | 3024 |
| Machine height (mm) | 3423 |
| Steering Angle | 35 |
| Ternary sum (s) | 9.3 |
| Speed 1 gear (km/h) | |
| Speed 2 (km/h) | |
| Maximum speed (km/h) | 38 |
