Product Description
This used Sumitomo SH130-6 hydraulic excavator is available from our Hubei, China location. This mid-size excavator from Sumitomo's respected construction equipment line offers reliable performance for general earthmoving, trenching, and material handling applications. The machine is reported to be in very good condition and notably has not been fitted with a breaker attachment or hammer piping system, suggesting lighter duty use throughout its operational life.
Key features of the Sumitomo SH130-6 include:
- 13-ton operating class suitable for medium-duty construction projects
- Sumitomo engineering known for fuel efficiency and durability
- No hammer piping previously installed, indicating preserved hydraulic system
- Currently located in Hubei, China with logistics support available
- Well-maintained condition as reported by seller
This excavator represents a cost-effective solution for contractors seeking dependable equipment for demolition, excavation, and site development work. Inspection welcomed.
| Specifications | Value |
|---|---|
| No. | 1051975 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12700 |
| Bucket capacity (m³) | 0.5-0.55 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 70.9/2000 |
| Displacement (L) | 2.999 |
| Rotation speed (rpm) | 14.1 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 91 |
| Rod digging force (kN) | 62 |
| Travel speed (km/h) | 5.6/3.4 |
| Main overflow set pressure (Mpa) | 34.3/36.3 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 34.3/36.3 |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 82 |
| Hydraulic System (L) | 157 |
| Total transport length (mm) | 7620 |
| Total transport width (mm) | 2540 |
| Total transport height (mm) | 2820 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 2340 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3500 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Maximum digging radius (mm) | 8310 |
| Maximum digging depth (mm) | 5540 |
| Maximum excavation height (mm) | 8770 |
| Maximum unloading height (mm) | 6390 |
| Maximum vertical digging depth (mm) | 4590 |
