Product Description
This 2020 Sumitomo 60 excavator is available for inspection and testing at our facility in Zhejiang, China. The machine has been maintained in excellent working condition and represents a reliable solution for contractors seeking proven Japanese engineering at competitive pricing.
- Year: 2020
- Brand: Sumitomo
- Model: 60
- Location: Zhejiang, China
- Condition: Well-maintained, ready for operation
- Inspection: On-site viewing and test operation available
Sumitomo excavators are recognized for durability and fuel efficiency in demanding applications. This unit is suited for general construction, excavation, and material handling tasks. Pricing is negotiable for qualified buyers. Contact us to schedule an inspection or request additional operational details and documentation.
| Specifications | Value |
|---|---|
| No. | 1110343 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 36400 |
| Bucket capacity (m³) | 1.6-1.8 |
| Boom length (mm) | 6400 |
| Rod length (mm) | 3200 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu GH-6HK1X |
| Rated power (kw/rpm) | 200/2000 |
| Displacement (L) | 7.79 |
| Rotation speed (rpm) | 10.2 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 232 |
| Rod digging force (kN) | 164 |
| Travel speed (km/h) | 5.4/3.4 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 34.3/37.3 |
| Fuel Tank (L) | 580 |
| Hydraulic Tank (L) | 175 |
| Hydraulic System (L) | 350 |
| Total transport length (mm) | 11140 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3420 |
| Counterweight ground clearance (mm) | 1200 |
| Minimum ground clearance (mm) | 480 |
| Minimum turning radius of front working device (mm) | 4500 |
| Back end turning radius (mm) | 3550 |
| Total track length (mm) | 4650 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3200 |
| Maximum digging radius (mm) | 11170 |
| Maximum digging depth (mm) | 7340 |
| Maximum excavation height (mm) | 10370 |
| Maximum unloading height (mm) | 7230 |
| Maximum vertical digging depth (mm) | 6350 |
