Product Description
Expand your fleet capacity with this reliable 2018 Sumitomo SH130-3 excavator, currently located in Hunan Province. Built as a joint-venture model originating from Xiamen, this 13-ton machine delivers consistent performance for contractors managing multiple jobsites or requiring dependable backup equipment during peak seasons.
Powered by an Isuzu AJ-4JJ1X turbocharged diesel engine producing 70.9 kW at 2000 rpm, this excavator combines proven hydraulic technology with practical dimensions. The 5,850mm boom and 2,500mm arm provide an impressive 8,310mm maximum digging reach and 5,540mm digging depth, while the 0.5m³ bucket handles standard excavation tasks efficiently.
- Working weight: 12,300 kg with optimal 40 kPa ground pressure
- Dual variable axial piston pumps ensure responsive hydraulic flow
- Compact transport dimensions (7,620 × 2,540 × 2,790mm) simplify logistics
- 260L fuel tank and 157L hydraulic reservoir support extended operation
- Water-cooled 4-cylinder engine (2.999L displacement) ensures reliability
Ideal for contractors seeking operational redundancy without compromising capability, this SH130-3 integrates seamlessly into existing fleets while maintain
| Specifications | Value |
|---|---|
| No. | 1012776 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12300 |
| Bucket capacity (m³) | 0.5 |
| Boom length (mm) | 5850 |
| Rod length (mm) | 2500 |
| Country of origin | Xiamen (in Fujian Province) |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AJ-4JJ1X |
| Rated power (kw/rpm) | 70.9/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.999 |
| Working form | Four-stroke, direct injection, fully electronically controlled, turbocharged diesel engine with intercooling |
| Ground specific pressure (Kpa) | 40 |
| Rotation speed (rpm) | 14.3 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | |
| Rod digging force (kN) | |
| Travel speed (km/h) | 3.4/5.6 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Quantitative axial piston motor |
| Type of walking hydraulic motor | Variable axial piston motor |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable axial piston pump ×2+ gear pump |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 157 |
| Total transport length (mm) | 7620 |
| Total transport width (mm) | 2540 |
| Total transport height (mm) | 2790 |
| Full cab height (mm) | 2790 |
| Counterweight ground clearance (mm) | 895 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 2340 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3500 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 2790 |
| Maximum digging radius (mm) | 8310 |
| Maximum digging depth (mm) | 5540 |
| Maximum excavation height (mm) | 8770 |
| Maximum unloading height (mm) | 6390 |
| Maximum vertical digging depth (mm) | 4950 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
