Product Description
Based in Fujian Putian and available for immediate dispatch, this 2018 Sumitomo SH130-3 delivers 13-ton performance without the wait. Skip factory lead times—this joint-venture manufactured excavator is ready for fast deployment to your site today. Powered by a turbocharged Isuzu AJ-4JJ1X engine producing 70.9kW, it combines proven reliability with fuel-efficient water-cooled operation across demanding jobsites.
- Immediate Availability: Fujian Putian location ensures rapid logistics throughout Southeast Asia and global markets
- Working Specs: 12,300 kg operating weight | 0.5 m³ bucket capacity | 8,310 mm maximum reach
- Versatile Digging: 5,540 mm max depth | 8,770 mm max height | 5,850 mm boom with 2,500 mm arm
- Hydraulic System: Dual variable axial piston pumps | 34.3 MPa main pressure | quantitative rotation motor
- Mobility: 14.3 rpm swing speed | 5.6 km/h travel | 70% grading capability | 2,340 mm tight turning radius
- Capacity: 260L fuel tank | 157L hydraulic reservoir for extended operation cycles
Sourced from Xiamen, this machine represents excepti
| Specifications | Value |
|---|---|
| No. | 1018065 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12300 |
| Bucket capacity (m³) | 0.5 |
| Boom length (mm) | 5850 |
| Rod length (mm) | 2500 |
| Country of origin | Xiamen (in Fujian Province) |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AJ-4JJ1X |
| Rated power (kw/rpm) | 70.9/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.999 |
| Working form | Four-stroke, direct injection, fully electronically controlled, turbocharged diesel engine with intercooling |
| Ground specific pressure (Kpa) | 40 |
| Rotation speed (rpm) | 14.3 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | |
| Rod digging force (kN) | |
| Travel speed (km/h) | 3.4/5.6 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Quantitative axial piston motor |
| Type of walking hydraulic motor | Variable axial piston motor |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable axial piston pump ×2+ gear pump |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 157 |
| Total transport length (mm) | 7620 |
| Total transport width (mm) | 2540 |
| Total transport height (mm) | 2790 |
| Full cab height (mm) | 2790 |
| Counterweight ground clearance (mm) | 895 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 2340 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3500 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 2790 |
| Maximum digging radius (mm) | 8310 |
| Maximum digging depth (mm) | 5540 |
| Maximum excavation height (mm) | 8770 |
| Maximum unloading height (mm) | 6390 |
| Maximum vertical digging depth (mm) | 4950 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
