Product Description
Expand your operational capacity with this 2019 Sumitomo SH130-5, a proven 13-ton excavator engineered for contractors who need reliable backup power without downtime risk. Sourced from Fujian Putian, this joint-venture manufactured unit delivers consistent performance across residential, utility, and light commercial projects where fleet availability drives profitability.
Powered by a 70.9kW four-cylinder engine, this machine combines a 0.55m³ bucket with 8,320mm maximum reach and 5,550mm digging depth—ideal specifications for trench work, foundation prep, and material handling. The 4,630mm boom and 2,500mm arm provide versatile geometry that mirrors your primary fleet's capabilities, ensuring operators transition seamlessly between machines.
- 12,500kg working weight optimized for site mobility and transport efficiency
- 90kN bucket digging force tackles compacted soils and aggregate materials
- 34.3MPa hydraulic system maintains productivity through extended shifts
- Compact 7,620mm transport length simplifies logistics between jobsites
Maintain project schedules when your lead machines undergo maintenance. This SH130-5 integrates immediately into multi-unit operatio
| Specifications | Value |
|---|---|
| No. | 1014549 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12500 |
| Bucket capacity (m³) | 0.55 |
| Boom length (mm) | 4630 |
| Rod length (mm) | 2500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 70.9//2000 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.999 |
| Ground specific pressure (Kpa) | 40 |
| Rotation speed (rpm) | 14.3 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 90 |
| Rod digging force (kN) | 62 |
| Travel speed (km/h) | 3.4/5.6 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 82 |
| Hydraulic System (L) | 157 |
| Total transport length (mm) | 7620 |
| Total transport width (mm) | 2500 |
| Total transport height (mm) | 2820 |
| Full cab height (mm) | 2820 |
| Counterweight ground clearance (mm) | 895 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 2340 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3500 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Maximum digging radius (mm) | 8320 |
| Maximum digging depth (mm) | 5550 |
| Maximum excavation height (mm) | 8780 |
| Maximum unloading height (mm) | 6380 |
| Maximum vertical digging depth (mm) | 4960 |
