Product Description
Built for demanding excavation and grading operations, this 2018 Sumitomo SH130-6 delivers 70.9kW of proven power in a versatile 13-ton platform. Currently located in Zhejiang Shaoxing, this joint venture-manufactured excavator arrives site-ready with a 0.5-0.55m³ backhoe bucket, 4600mm boom, and 2500mm arm engineered for precision digging and material handling. Reach extends to 8310mm maximum digging radius with 5540mm depth capability, while 91kN bucket digging force and 62kN arm force tackle compacted soil and stubborn ground conditions without hesitation.
Performance specifications include:
- 12,700kg working weight optimized for stability and maneuverability
- 70% grading ability conquers steep terrain and loading ramps
- Variable capacity piston pump hydraulic system operating at 34.3/36.3MPa
- Dual travel speeds (5.6/3.4 km/h) for efficient site navigation
- 260L fuel capacity minimizes refueling downtime during extended shifts
- Compact 2540mm transport width fits standard trailers and tight access points
Ready to deploy on excavation, trenching, grading, and demolition projects. Inspect in Shaoxing.
| Specifications | Value |
|---|---|
| No. | 1028923 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12700 |
| Bucket capacity (m³) | 0.5-0.55 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 70.9/2000 |
| Displacement (L) | 2.999 |
| Rotation speed (rpm) | 14.1 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 91 |
| Rod digging force (kN) | 62 |
| Travel speed (km/h) | 5.6/3.4 |
| Main overflow set pressure (Mpa) | 34.3/36.3 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 34.3/36.3 |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 82 |
| Hydraulic System (L) | 157 |
| Total transport length (mm) | 7620 |
| Total transport width (mm) | 2540 |
| Total transport height (mm) | 2820 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 2340 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3500 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Maximum digging radius (mm) | 8310 |
| Maximum digging depth (mm) | 5540 |
| Maximum excavation height (mm) | 8770 |
| Maximum unloading height (mm) | 6390 |
| Maximum vertical digging depth (mm) | 4590 |
