Product Description
Built for endurance and engineered to perform, this 2020 Sumitomo SH130-6 excavator delivers proven reliability in demanding construction environments. With 13 tons of working capacity and a robust 70.9kW engine, this machine has demonstrated its durability through consistent operation since manufacture.
Key performance specifications showcase its industrial strength:
- Maximum digging depth of 5,540mm with 0.5-0.55m³ bucket capacity
- Impressive 8,310mm maximum digging radius for versatile reach
- 91kN bucket digging force ensuring efficient material handling
- 260L fuel tank capacity supporting extended operational periods
- Compact 2,540mm transport width for enhanced job site mobility
Currently located in Fujian Putian, this proven workhorse represents Sumitomo's commitment to manufacturing excavators that withstand rigorous daily use. Four years of operation have validated its mechanical integrity and hydraulic system reliability. The SH130-6's track record speaks to its ability to maintain productivity standards while delivering consistent performance across diverse applications.
| Specifications | Value |
|---|---|
| No. | 991566 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12700 |
| Bucket capacity (m³) | 0.5-0.55 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 70.9/2000 |
| Displacement (L) | 2.999 |
| Rotation speed (rpm) | 14.1 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 91 |
| Rod digging force (kN) | 62 |
| Travel speed (km/h) | 5.6/3.4 |
| Main overflow set pressure (Mpa) | 34.3/36.3 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 34.3/36.3 |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 82 |
| Hydraulic System (L) | 157 |
| Total transport length (mm) | 7620 |
| Total transport width (mm) | 2540 |
| Total transport height (mm) | 2820 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 2340 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3500 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Maximum digging radius (mm) | 8310 |
| Maximum digging depth (mm) | 5540 |
| Maximum excavation height (mm) | 8770 |
| Maximum unloading height (mm) | 6390 |
| Maximum vertical digging depth (mm) | 4590 |
