Product Description
Built for demanding excavation work, this 2016 Sumitomo SH200-3 delivers reliable performance across construction and earthmoving applications. Operating at 20 tons with a robust 19,100 kg working weight, this machine tackles digging, grading, and material handling with proven efficiency. The ISUZU BB-6BG1T engine generates 103 kW at 1950 rpm, providing consistent power through a water-cooled, 6-cylinder configuration with 6.494L displacement.
Equipped with a 0.8 m³ backhoe bucket, this excavator reaches a maximum digging depth of 6,710 mm and extends to 9,960 mm digging radius. Bucket digging force measures 130 kN, while rod digging force delivers 93.5 kN for breaking through compacted materials. The 70% climbing ability and 460 mm ground clearance ensure mobility on challenging terrain.
- Maximum excavation height: 9,650 mm
- Travel speed: 3.3/5.5 km/h for efficient repositioning
- 340L fuel tank and 206L hydraulic tank for extended operation
- Compact transport dimensions: 9,390 mm × 2,800 mm × 2,910 mm
- Currently located in Guizhou, ready for immediate deployment
Site-ready and field-tested, this machine stands prepared to meet your project requirements.
| Specifications | Value |
|---|---|
| No. | 1009864 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 19100 |
| Bucket capacity (m³) | 0.8 |
| Country of origin | |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU BB-6BG1T |
| Rated power (kw/rpm) | 103/1950 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.494 |
| Rotation speed (rpm) | 11.9 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 130 |
| Rod digging force (kN) | 93.5 |
| Travel speed (km/h) | 3.3/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | |
| Main pump type | |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 206 |
| Total transport length (mm) | 9390 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2910 |
| Full cab height (mm) | 2910 |
| Minimum ground clearance (mm) | 460 |
| Minimum turning radius of front working device (mm) | 3620 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4180 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Maximum digging radius (mm) | 9960 |
| Maximum digging depth (mm) | 6710 |
| Maximum excavation height (mm) | 9650 |
| Maximum unloading height (mm) | 6840 |
| Maximum vertical digging depth (mm) | 6080 |
