2020 Sumitomo SH200-3

Name: Used Excavators 2020 Sumitomo SH200-3
Brand: Sumitomo
SKU: USED-1056886
Availability: InStock
Rating: 4.8 (68 reviews)

1/8

Product Description

Discover the reliability and efficiency of the 2020 Sumitomo SH200-3, a robust excavator available in Zhejiang, China. This machine has been under single ownership since its first use, ensuring consistent maintenance and care. With an operational history of approximately 40,000 hours, this SH200-3 is well-suited for demanding construction and excavation projects. Known for its durability and performance, it is equipped to handle a variety of tasks, making it a valuable addition to any fleet.

Year: 2020
Brand: Sumitomo
Model: SH200-3
Location: Zhejiang, China
Operational Hours: ~40,000

Specifications	Value
No.	1056886
Tonnage (tons)	20
Working weight (kg)	19100
Bucket capacity (m³)	0.8
Country of origin
power	Traditional power
manufacturer	Joint venture/Import
bucket	backhoe
Engine type	ISUZU BB-6BG1T
Rated power (kw/rpm)	103/1950
Cooling mode	water-cooling
Number of cylinders (PCS)	6
Displacement (L)	6.494
Rotation speed (rpm)	11.9
Climbing ability (%)	70/35 °
Bucket digging force (kN)	130
Rod digging force (kN)	93.5
Travel speed (km/h)	3.3/5.5
Main overflow set pressure (Mpa)	34.3
Rotary hydraulic motor type
Type of walking hydraulic motor
Main pump type
Fuel Tank (L)	340
Hydraulic Tank (L)	206
Total transport length (mm)	9390
Total transport width (mm)	2800
Total transport height (mm)	2910
Full cab height (mm)	2910
Minimum ground clearance (mm)	460
Minimum turning radius of front working device (mm)	3620
Back end turning radius (mm)	2750
Total track length (mm)	4180
Track gauge (mm)	2200
Track plate width (mm)	600
Total track width (mm)	2800
Maximum digging radius (mm)	9960
Maximum digging depth (mm)	6710
Maximum excavation height (mm)	9650
Maximum unloading height (mm)	6840
Maximum vertical digging depth (mm)	6080
