Product Description
Built for demanding excavation work, this 2021 Sumitomo SH210-5 delivers 21 tons of proven performance on any jobsite. Powered by a robust 117.3 kW engine with 5.193L displacement, this machine tackles digging, grading, and material handling with consistent reliability. The 5700mm boom and 2900mm arm provide a maximum digging reach of 9900mm and depth of 6650mm, making it ideal for foundation work, trenching, and site preparation tasks.
Equipped with a 0.9-1.0 m³ bucket capacity and impressive digging forces—142 kN bucket force and 103 kN arm force—this excavator moves material efficiently throughout your shift. The variable axial piston motor delivers precise control, while the 422 L/min main pump flow ensures responsive hydraulic performance. With a 70% climbing ability and dual travel speeds (3.4/5.6 km/h), maneuver confidently across challenging terrain.
Currently located in Hefei, Anhui, this site-ready machine features:
- 20,600 kg working weight for stability during heavy operations
- 410L fuel capacity for extended runtime
- 2800mm transport width for easy mobilization
- 11.5 rpm rotation speed for efficient cycle times
Ready to perform from day one on demolition
| Specifications | Value |
|---|---|
| No. | 1008581 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 20600 |
| Bucket capacity (m³) | 0.9-1.0 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 117.3/1800 |
| Cylinder diameter × stroke (mm) | 115 x 125 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 5.193 |
| Ground specific pressure (Kpa) | 45 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 142 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 3.4/5.6 |
| Type of walking hydraulic motor | Variable axial piston motor |
| Maximum flow of main pump (l/min) | 422 |
| Main pump type | |
| Bucket cylinders - Number × diameter × stroke (mm) | |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 140 x 1460 |
| Boom cylinders - Number × diameter × stroke (mm) | |
| Fuel Tank (L) | 410 |
| Hydraulic Tank (L) | 147 |
| Engine Oil changes (L) | 23.1 |
| Coolant (L) | 26 |
| Hydraulic System (L) | 240 |
| Total transport length (mm) | 9400 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2970 |
| Counterweight ground clearance (mm) | 1040 |
| Minimum ground clearance (mm) | 460 |
| Minimum turning radius of front working device (mm) | 3600 |
| Back end turning radius (mm) | 2720 |
| Total track length (mm) | 4180 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3370 |
| Maximum digging radius (mm) | 9900 |
| Maximum digging depth (mm) | 6650 |
| Maximum excavation height (mm) | 9610 |
| Maximum unloading height (mm) | 6810 |
| Maximum vertical digging depth (mm) | 5960 |
