Product Description
Expand your operational capacity with this proven 2017 Sumitomo SH210-6 excavator, currently located in Kunming, Yunnan. Built for contractors managing multiple job sites, this 21-ton workhorse delivers consistent performance with a powerful 117.3kW engine and 0.85-1.0m³ bucket capacity. Whether you need a reliable backup during peak season or want to diversify your fleet capabilities, this joint-venture manufactured machine offers the durability Sumitomo is known for without the premium price of new equipment.
- Maximum digging reach: 9,900mm with impressive 6,650mm depth capability
- Dual boom configurations (5,700mm) with 2,900mm/2,400mm rod options for versatile applications
- Robust hydraulic system: 142kN bucket force, 103kN arm force for tough excavation
- Compact transport dimensions (9,400mm × 2,800mm × 2,970mm) for easy mobilization between sites
- Efficient fuel management with 410L tank capacity for extended operation
- 70% gradeability and 11.5rpm swing speed maintain productivity on challenging terrain
Maintain project momentum and avoid costly downtime. This SH210-6 integrates seamlessly with existing Sumitomo fleets while offering cross-compati
| Specifications | Value |
|---|---|
| No. | 1031821 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21000 |
| Bucket capacity (m³) | 0.85~1.0 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900 / 2400 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 117.3/1800 |
| Displacement (L) | 5.193 |
| Ground specific pressure (Kpa) | 47 / 36 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 142 / 152 |
| Rod digging force (kN) | 103 / 110 |
| Travel speed (km/h) | 5.6 / 3.4 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 34.3 / 36.8 |
| Fuel Tank (L) | 410 |
| Hydraulic Tank (L) | 147 |
| Hydraulic System (L) | 240 |
| Total transport length (mm) | 9400 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2970 |
| Counterweight ground clearance (mm) | 1040 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3600 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4180 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3370 |
| Maximum digging radius (mm) | 9900/9420 |
| Maximum digging depth (mm) | 6650/6110 |
| Maximum excavation height (mm) | 9610/9410 |
| Maximum unloading height (mm) | 6810/6590 |
| Maximum vertical digging depth (mm) | 5960/5500 |
