Product Description
With a robust 21-ton working weight and a powerful 117.3 kW engine, this 2020 Sumitomo SH210-6 excavator is site-ready for demanding tasks. Equipped with a versatile backhoe bucket, it delivers exceptional digging force up to 152 kN, making it ideal for excavation and demolition projects. The machine features a 5.193 L displacement engine, ensuring reliable performance on any job site. Its maximum digging depth of 6650 mm and maximum digging radius of 9900 mm provide the reach needed for extensive earthwork. Capable of climbing gradients up to 70%, this excavator can handle rough terrain with ease. Additionally, its 5.6 km/h travel speed and 11.5 rpm rotation speed enhance maneuverability and efficiency. Ready to work immediately, the SH210-6 is a dependable choice for your heavy machinery needs.
- Bucket capacity: 0.85~1.0 m³
- Boom length: 5700 mm
- Rod lengths: 2900 / 2400 mm
- Total transport dimensions: 9400 x 2800 x 2970 mm
- Fuel tank capacity: 410 L
- Hydraulic tank capacity: 147 L
| Specifications | Value |
|---|---|
| No. | 1030783 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21000 |
| Bucket capacity (m³) | 0.85~1.0 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900 / 2400 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 117.3/1800 |
| Displacement (L) | 5.193 |
| Ground specific pressure (Kpa) | 47 / 36 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 142 / 152 |
| Rod digging force (kN) | 103 / 110 |
| Travel speed (km/h) | 5.6 / 3.4 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 34.3 / 36.8 |
| Fuel Tank (L) | 410 |
| Hydraulic Tank (L) | 147 |
| Hydraulic System (L) | 240 |
| Total transport length (mm) | 9400 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2970 |
| Counterweight ground clearance (mm) | 1040 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3600 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4180 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3370 |
| Maximum digging radius (mm) | 9900/9420 |
| Maximum digging depth (mm) | 6650/6110 |
| Maximum excavation height (mm) | 9610/9410 |
| Maximum unloading height (mm) | 6810/6590 |
| Maximum vertical digging depth (mm) | 5960/5500 |
