Product Description
Built for precision and reliability, this 2021 Sumitomo SH210-6 excavator delivers exceptional operator control with its advanced hydraulic system and spacious cabin design. Operating at 21 tons with 117.3kW of power, this machine provides superior stability through its 2800mm track width and optimized weight distribution.
Key operational advantages include:
- Enhanced visibility from elevated operator position with panoramic cabin windows
- Responsive joystick controls with precise hydraulic feedback at 34.3 MPa working pressure
- Stable platform operation with 47 KPa ground pressure and 70% climbing capability
- Comfortable ergonomic seating with vibration dampening for extended work shifts
- Intuitive dashboard layout with clear instrument visibility and easy-access controls
With 0.85-1.0m³ bucket capacity and 9900mm maximum digging radius, operators can efficiently handle diverse excavation tasks while maintaining excellent machine control. The reinforced undercarriage and proven Sumitomo engineering ensure dependable performance in demanding construction environments. Currently located in Zhejiang province, ready for immediate deployment.
| Specifications | Value |
|---|---|
| No. | 991500 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21000 |
| Bucket capacity (m³) | 0.85~1.0 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900 / 2400 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 117.3/1800 |
| Displacement (L) | 5.193 |
| Ground specific pressure (Kpa) | 47 / 36 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 142 / 152 |
| Rod digging force (kN) | 103 / 110 |
| Travel speed (km/h) | 5.6 / 3.4 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 34.3 / 36.8 |
| Fuel Tank (L) | 410 |
| Hydraulic Tank (L) | 147 |
| Hydraulic System (L) | 240 |
| Total transport length (mm) | 9400 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2970 |
| Counterweight ground clearance (mm) | 1040 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3600 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4180 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3370 |
| Maximum digging radius (mm) | 9900/9420 |
| Maximum digging depth (mm) | 6650/6110 |
| Maximum excavation height (mm) | 9610/9410 |
| Maximum unloading height (mm) | 6810/6590 |
| Maximum vertical digging depth (mm) | 5960/5500 |
