Product Description
Built in 2019, this Sumitomo SH260LC-6 excavator represents proven Japanese engineering backed by comprehensive global parts networks. Operating at 26 tons with a 132.1kW engine, this machine delivers consistent performance across demanding jobsites while maintaining exceptional resale value in international markets.
Sumitomo's reputation for durability translates directly into lower total ownership costs. The SH260LC-6 features a 1.3m³ bucket capacity, 10,280mm maximum digging radius, and 6,900mm digging depth—specifications that remain competitive years after manufacture. Currently located in Hunan, this unit benefits from readily available OEM and aftermarket components through established supply chains.
- Working weight: 25,500kg with 5,850mm boom and 3,000mm arm
- Hydraulic system: 34.3/36.8 Mpa operating pressure with 250L capacity
- Transport dimensions: 9,930mm × 3,190mm × 3,150mm
- Fuel efficiency: 410L tank supporting extended operation cycles
- Climbing ability: 70% grade capability with 50 Kpa ground pressure
Investing in Sumitomo means securing predictable maintenance schedules and strong secondary market demand—critical factors for equipment buyers prioriti
| Specifications | Value |
|---|---|
| No. | 1019502 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.3 |
| Boom length (mm) | 5850 |
| Rod length (mm) | 3000 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 132.1/2000 |
| Displacement (L) | 5.193 |
| Ground specific pressure (Kpa) | 50 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 162/174 |
| Rod digging force (kN) | 120/129 |
| Travel speed (km/h) | 5.5/3.5 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 34.3/36.8 |
| Fuel Tank (L) | 410 |
| Hydraulic Tank (L) | 147 |
| Hydraulic System (L) | 250 |
| Total transport length (mm) | 9930 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1100 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3950 |
| Back end turning radius (mm) | 2950 |
| Total track length (mm) | 4650 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6900 |
| Maximum excavation height (mm) | 9760 |
| Maximum unloading height (mm) | 6760 |
| Maximum vertical digging depth (mm) | 6140 |
