Product Description
Ready to deploy from 广东揭阳 (Guangdong Jieyang), this 2016 Sumitomo SH350-3B excavator delivers 35-ton performance without factory wait times. Powered by a 202kW water-cooled, 6-cylinder turbocharged diesel engine with intercooling, this machine combines proven reliability with immediate availability for your next project.
Built for demanding applications, the SH350-3B features a 6,400mm boom and 3,200mm arm configuration, achieving a maximum digging reach of 11,170mm and depth of 7,340mm. The 1.2-1.8m³ bucket capacity handles high-volume earthmoving efficiently, while dual variable axial piston pumps ensure responsive hydraulic performance at 34.3MPa system pressure.
Key Specifications:
- Operating weight: 35,200kg with 600/800mm track plates
- Travel speeds: 3.5/5.5 km/h for optimal site mobility
- 580L fuel capacity supports extended shift operations
- 9.8 rpm swing speed and 70% gradeability
- Transport dimensions: 11,050mm × 3,200mm × 3,260mm
Available now for fast shipment worldwide. Skip months of lead time and put this field-proven excavator to work immediately. Contact Fair Trade Machinery today for pricing and logistics coordination from G
| Specifications | Value |
|---|---|
| No. | 1044146 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 35200 |
| Bucket capacity (m³) | 1.2-1.8 |
| Boom length (mm) | 6400 |
| Rod length (mm) | 3200 |
| Country of origin | Xiamen (in Fujian Province) |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 202/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 0.779 |
| Working form | Four-stroke, direct injection, fully electronically controlled, turbocharged diesel engine with intercooling |
| Ground specific pressure (Kpa) | 71 |
| Rotation speed (rpm) | 9.8 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | |
| Rod digging force (kN) | |
| Travel speed (km/h) | 3.5/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Quantitative axial piston motor |
| Type of walking hydraulic motor | Variable axial piston motor |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable axial piston pump ×2+ gear pump ×1 |
| Fuel Tank (L) | 580 |
| Hydraulic Tank (L) | 350 |
| Total transport length (mm) | 11050 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3260 |
| Full cab height (mm) | 3130 |
| Counterweight ground clearance (mm) | 1210 |
| Minimum ground clearance (mm) | 480 |
| Minimum turning radius of front working device (mm) | 4500 |
| Back end turning radius (mm) | 3450 |
| Total track length (mm) | 4650 |
| Track gauge (mm) | 2600 |
| Track plate width (mm) | 600/800 |
| Total track width (mm) | 3200 |
| Track ground length (mm) | 3720 |
| Maximum digging radius (mm) | 11170 |
| Maximum digging depth (mm) | 7340 |
| Maximum excavation height (mm) | 10370 |
| Maximum unloading height (mm) | 7230 |
| Maximum vertical digging depth (mm) | 6350 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
