Product Description
Built for high-volume earthmoving and deep excavation work, this 2012 Sumitomo SH350-5 delivers 35 tons of proven productivity. Powered by a robust AH-6HK1XYSS engine generating 202 kW at 2000 rpm, this machine tackles demanding site conditions with authority. Maximum digging depth reaches 7,340 mm while the 11,170 mm reach puts material exactly where you need it.
Equipped with a 1.2-1.8 m³ bucket capacity and 229 kN bucket digging force, this excavator moves serious volume on trenching, foundation, and demolition projects. The 70% climbing ability and 480 mm ground clearance ensure access across challenging terrain. With 580L fuel capacity and 350L hydraulic tank, expect extended operating sessions without interruption.
- Working Weight: 35,200 kg
- Rated Power: 202 kW @ 2000 rpm
- Maximum Digging Reach: 11,170 mm
- Maximum Digging Depth: 7,340 mm
- Bucket Digging Force: 229 kN
- Transport Dimensions: 11,050 × 3,200 × 3,260 mm
- Location: Hunan, China
Site-ready condition. Ready to load and ship worldwide.
| Specifications | Value |
|---|---|
| No. | 1021819 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 35200 |
| Bucket capacity (m³) | 1.2-1.8 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | AH-6HK1XYSS |
| Rated power (kw/rpm) | 202/2000 |
| Displacement (L) | 7.79 |
| Ground specific pressure (Kpa) | 71 |
| Rotation speed (rpm) | 9.8 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 164 |
| Maximum tractive force (kN) | 264 |
| Travel speed (km/h) | 5.5/3.5 |
| Main overflow set pressure (Mpa) | 34.3/37.3 |
| Fuel Tank (L) | 580 |
| Hydraulic Tank (L) | 350 |
| Total transport length (mm) | 11050 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3260 |
| Minimum ground clearance (mm) | 480 |
| Minimum turning radius of front working device (mm) | 4500 |
| Back end turning radius (mm) | 3450 |
| Total track length (mm) | 4650 |
| Track gauge (mm) | 2600 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3200 |
| Maximum digging radius (mm) | 11170 |
| Maximum digging depth (mm) | 7340 |
| Maximum excavation height (mm) | 10370 |
| Maximum unloading height (mm) | 7230 |
| Maximum vertical digging depth (mm) | 6350 |
