Proven performance meets legendary Japanese engineering in this 2014 Sumitomo SH350-5 excavator, now available from our Fujian Putian facility. With 35 tons of working weight and a robust 202kW AH-6HK1XYSS engine, this machine has demonstrated its reliability over years of demanding operation. Equipped with a 1.2-1.8m³ backhoe bucket and an impressive 11,170mm maximum digging radius, it delivers consistent productivity across diverse applications.
- Built to Last: Joint venture construction ensures superior durability and component quality
- Exceptional Reach: 7,340mm maximum digging depth and 10,370mm maximum excavation height
- Powerful Performance: 229kN bucket digging force with 7.79L displacement engine
- Proven Workhorse: 70% climbing ability and 5.5km/h travel speed for challenging terrain
- Field-Tested Reliability: Years of operational history validate this machine's exceptional build quality
Complete with 580L fuel capacity and comprehensive hydraulic systems, this SH350-5 represents a smart investment in time-tested heavy equipment technology.
| Specifications | Value |
|---|---|
| No. | 1030146 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 35200 |
| Bucket capacity (m³) | 1.2-1.8 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | AH-6HK1XYSS |
| Rated power (kw/rpm) | 202/2000 |
| Displacement (L) | 7.79 |
| Ground specific pressure (Kpa) | 71 |
| Rotation speed (rpm) | 9.8 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 164 |
| Maximum tractive force (kN) | 264 |
| Travel speed (km/h) | 5.5/3.5 |
| Main overflow set pressure (Mpa) | 34.3/37.3 |
| Fuel Tank (L) | 580 |
| Hydraulic Tank (L) | 350 |
| Total transport length (mm) | 11050 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3260 |
| Minimum ground clearance (mm) | 480 |
| Minimum turning radius of front working device (mm) | 4500 |
| Back end turning radius (mm) | 3450 |
| Total track length (mm) | 4650 |
| Track gauge (mm) | 2600 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3200 |
| Maximum digging radius (mm) | 11170 |
| Maximum digging depth (mm) | 7340 |
| Maximum excavation height (mm) | 10370 |
| Maximum unloading height (mm) | 7230 |
| Maximum vertical digging depth (mm) | 6350 |
