2020 Sumitomo SH350-5

1/6
Buy Sumitomo SH350-5 Used Excavator / 1
Buy Sumitomo SH350-5 Used Excavator / 2
Buy Sumitomo SH350-5 Used Excavator / 3
Buy Sumitomo SH350-5 Used Excavator / 4
Buy Sumitomo SH350-5 Used Excavator / 5
Buy Sumitomo SH350-5 Used Excavator / 6

Product Description

This 2020 Sumitomo SH350-5 hydraulic excavator is now available from Fujian, China. With approximately 6 years in service, this 35-ton class machine features Sumitomo's proven reliability and performance standards expected from Japanese engineering.

The SH350-5 is well-suited for medium to heavy-duty excavation, demolition, and material handling applications. This unit is currently located in Fujian Province and is being offered for immediate sale due to owner circumstances requiring quick liquidation.

  • Year of Manufacture: 2020
  • Model: Sumitomo SH350-5
  • Operating Weight Class: 35 tonnes
  • Current Location: Fujian Province, China
  • Equipped with hydraulic breaker attachment
  • Competitively priced for quick sale

Inspection is recommended prior to purchase. Contact us for detailed specifications, current hour meter reading, and shipping arrangements.

SpecificationsValue
No.1084108
Tonnage (tons)35
Working weight (kg)35200
Bucket capacity (m³)1.2-1.8
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeAH-6HK1XYSS
Rated power (kw/rpm)202/2000
Displacement (L)7.79
Ground specific pressure (Kpa)71
Rotation speed (rpm)9.8
Climbing ability (%)70
Bucket digging force (kN)229
Rod digging force (kN)164
Maximum tractive force (kN)264
Travel speed (km/h)5.5/3.5
Main overflow set pressure (Mpa)34.3/37.3
Fuel Tank (L)580
Hydraulic Tank (L)350
Total transport length (mm)11050
Total transport width (mm)3200
Total transport height (mm)3260
Minimum ground clearance (mm)480
Minimum turning radius of front working device (mm)4500
Back end turning radius (mm)3450
Total track length (mm)4650
Track gauge (mm)2600
Track plate width (mm)600
Total track width (mm)3200
Maximum digging radius (mm)11170
Maximum digging depth (mm)7340
Maximum excavation height (mm)10370
Maximum unloading height (mm)7230
Maximum vertical digging depth (mm)6350
see more

Overview

No.1084108

Brand Name:

Sumitomo

Model Number:

SH350-5

Year:

2020

Location:

Fujian China
