Product Description
Maximize your ROI with this 2018 Sumitomo SH380-5 excavator—a proven workhorse delivering flagship performance without the new equipment premium. Powered by an Isuzu AH-6HK1X engine generating 202 kW at 2000 rpm, this 38-ton machine handles demanding excavation, loading, and earthmoving operations with authority. Currently located in Putian, Fujian, it combines a 1.8 m³ bucket capacity with impressive reach specs: 11,170 mm maximum digging radius and 7,340 mm digging depth.
- Working Weight: 36,600 kg with optimal 68 kPa ground pressure
- Digging Power: 229 kN bucket force, 164 kN arm force—built for tough material
- Boom/Arm Configuration: 6,400 mm / 3,200 mm for versatile applications
- Hydraulic System: Variable piston pumps, 34.3/37.3 MPa working pressure
- Fuel Capacity: 580 L tank supports extended shifts
- Mobility: 70% gradeability, 5.5 km/h travel speed
Acquire joint venture quality at used equipment pricing. Smart operators choose proven reliability over depreciation.
| Specifications | Value |
|---|---|
| No. | 1028521 |
| Tonnage (tons) | 38 |
| Working weight (kg) | 36600 |
| Bucket capacity (m³) | 1.8 |
| Boom length (mm) | 6400 |
| Rod length (mm) | 3200 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AH-6HK1X |
| Rated power (kw/rpm) | 202/2000 |
| Displacement (L) | 7.790 |
| Ground specific pressure (Kpa) | 68 |
| Rotation speed (rpm) | 9.8 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 229 |
| Rod digging force (kN) | 164 |
| Maximum tractive force (kN) | 264 |
| Travel speed (km/h) | 5.5/3.5 |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | Variable capacity piston pump |
| Working Hydraulic Circuit (Mpa) | 34.3/37.3 |
| Fuel Tank (L) | 580 |
| Hydraulic Tank (L) | 175 |
| Hydraulic System (L) | 350 |
| Total transport length (mm) | 11050 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3260 |
| Minimum turning radius of front working device (mm) | 4500 |
| Back end turning radius (mm) | 3450 |
| Total track length (mm) | 4980 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3200 |
| Maximum digging radius (mm) | 11170 |
| Maximum digging depth (mm) | 7340 |
| Maximum excavation height (mm) | 10370 |
| Maximum unloading height (mm) | 7230 |
| Maximum vertical digging depth (mm) | 6350 |
