Product Description
Expand your fleet capacity with this 2018 Sumitomo SH480-5 excavator, a proven 48-ton workhorse engineered for high-output operations. Powered by a robust 270 kW engine delivering 1,950 rpm, this machine provides the reliability and performance demanded by contractors managing multiple job sites simultaneously. Currently located in Putian, Fujian, it arrives ready to integrate seamlessly into existing heavy-duty fleets.
- Maximum digging reach of 11,800 mm with 7,470 mm depth capability
- Powerful 243.3 kN bucket digging force handles tough excavation tasks
- 2.2-2.4 m³ bucket capacity optimizes cycle times and productivity
- 41,700 kg operating weight balances stability with transportability
- 650 L fuel tank supports extended operating shifts
- 70% (35°) climbing ability conquers challenging terrain conditions
Built by joint venture manufacturing standards, this SH480-5 serves as an ideal backup unit during peak demand periods or scheduled maintenance windows. Its consistent performance metrics and straightforward maintenance requirements minimize downtime across your equipment roster. Secure operational continuity with a machine designed for fleet integrati
| Specifications | Value |
|---|---|
| No. | 1030440 |
| Tonnage (tons) | 48 |
| Working weight (kg) | 41700 |
| Bucket capacity (m³) | 2.2-2.4 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 270/1950 |
| Maximum torque (N.m/rpm) | 98 |
| Ground specific pressure (Kpa) | 341 |
| Rotation speed (rpm) | 9 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 243.3 |
| Rod digging force (kN) | 221.4 |
| Travel speed (km/h) | |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | |
| Main pump type | |
| Fuel Tank (L) | 650 |
| Hydraulic Tank (L) | 230/460 |
| Total transport length (mm) | 12070 |
| Total transport width (mm) | 3350 |
| Total transport height (mm) | 3720 |
| Counterweight ground clearance (mm) | 1330 |
| Minimum ground clearance (mm) | 540 |
| Minimum turning radius of front working device (mm) | 5030 |
| Back end turning radius (mm) | 3690 |
| Total track length (mm) | 5100 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3350 |
| Maximum digging radius (mm) | 11800 |
| Maximum digging depth (mm) | 7470 |
| Maximum excavation height (mm) | 11130 |
| Maximum unloading height (mm) | 7710 |
| Maximum vertical digging depth (mm) | 5610 |
