Product Description
Proven in the field since 2018, this Sumitomo SH700LHD-5 exemplifies Japanese engineering excellence with its robust 70-ton platform and powerful ISUZU AH-6xyss engine delivering 345kW at 1800rpm. Operating weight of 68,100kg combines with a substantial 2.9m³ bucket capacity to tackle demanding excavation projects with confidence. Water-cooled 6-cylinder turbocharged diesel technology ensures consistent performance across extended duty cycles, while the 7,700mm boom and 3,550mm arm provide exceptional reach—maximum digging radius of 13,160mm and depth capability to 8,400mm.
Built to Last — Key Specifications:
- Quantitative axial piston rotation motor with 6.5rpm swing speed
- Variable piston travel motors enabling 3.0-4.1km/h ground speeds
- Factory-equipped hydraulic crushing pipeline for attachment versatility
- 900L fuel capacity supports extended operational periods
- 70% gradeability (35°) demonstrates superior mobility on challenging terrain
- Currently located in Hangzhou, Zhejiang—ready for global deployment
This proven workhorse represents joint-venture manufacturing quality, combining reliability with the performance metrics heavy constr
| Specifications | Value |
|---|---|
| No. | 1042932 |
| Tonnage (tons) | 70 |
| Working weight (kg) | 68100 |
| Bucket capacity (m³) | 2.9 |
| Boom length (mm) | 7700 |
| Rod length (mm) | 3550 |
| Country of origin | Xiamen (in Fujian Province) |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU AH-6xyss |
| Rated power (kw/rpm) | 345/1800 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 15.7 |
| Working form | Four-stroke, direct injection, fully electronically controlled, turbocharged diesel engine with intercooling |
| Ground specific pressure (Kpa) | 100 |
| Rotation speed (rpm) | 6.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | |
| Rod digging force (kN) | |
| Travel speed (km/h) | 3.0/4.1 |
| Main overflow set pressure (Mpa) | |
| Rotary hydraulic motor type | Quantitative axial piston motor |
| Type of walking hydraulic motor | Variable axial piston motor |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | |
| Fuel Tank (L) | 900 |
| Hydraulic Tank (L) | 310 |
| Total transport length (mm) | 13290 |
| Total transport width (mm) | 4140 |
| Total transport height (mm) | 4300 |
| Full cab height (mm) | 3480 |
| Counterweight ground clearance (mm) | 1510 |
| Minimum ground clearance (mm) | 825 |
| Minimum turning radius of front working device (mm) | 5810 |
| Back end turning radius (mm) | 4000 |
| Total track length (mm) | 5880 |
| Track gauge (mm) | 4700 |
| Track plate width (mm) | 650 |
| Total track width (mm) | 3990 |
| Track ground length (mm) | 4700 |
| Maximum digging radius (mm) | 13160 |
| Maximum digging depth (mm) | 8400 |
| Maximum excavation height (mm) | 11920 |
| Maximum unloading height (mm) | 8020 |
| Maximum vertical digging depth (mm) | 6870 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
Overview
No.1042932
Brand Name：
SumitomoModel Number：
SH700LHD-5Year：
2018
Location：
Zhejiang China
Pub Date：
