Designed for precision work in confined spaces, this 2017 Sumitomo SH80-3B delivers exceptional operator control across demanding jobsites. Weighing 8,500 kg with an 8-ton capacity, this compact excavator combines maneuverability with stable performance. The Isuzu AU-4LE2X engine generates 40 kW at 2000 rpm, providing consistent power for backhoe operations with a 0.28 m³ bucket capacity.
Operator efficiency remains central to this machine's design. A compact 1,630 mm rear turning radius enables work in restricted areas, while 360 mm ground clearance maintains stability on uneven terrain. The cabin positioning offers clear sightlines to the 7,270 mm maximum excavation radius and 4,590 mm maximum digging depth. Responsive hydraulics and intuitive controls reduce operator fatigue during extended shifts.
- Maximum vertical digging depth: 3,350 mm
- Maximum unloading height: 4,600 mm
- Travel speed: 5.1 km/h
- 450 mm track plate width for enhanced stability
- Compact transport dimensions: 6,740 × 2,320 × 2,700 mm
Currently located in Luzhou, Sichuan, this joint venture-manufactured unit represents proven reliability for contractors prioritizing operator comfort and jobsite p
| Specifications | Value |
|---|---|
| No. | 996821 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 8500 |
| Bucket capacity (m³) | 0.28 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AU-4LE2X |
| Rated power (kw/rpm) | 40/2000 |
| Displacement (L) | 2.2 |
| Total transport length (mm) | 6740 |
| Total transport width (mm) | 2320 |
| Total transport height (mm) | 2700 |
| Minimum ground clearance (mm) | 360 |
| Back end turning radius (mm) | 1630 |
| Track plate width (mm) | 450 |
| Track ground length (mm) | 2210 |
| Maximum digging depth (mm) | 4590 |
| Maximum unloading height (mm) | 4600 |
| Maximum vertical digging depth (mm) | 3350 |
| Maximum excavation radius of stop surface (mm) | 7270 |
| Travel speed (km/h) | 5.1 |
