Product Description
Engineered with precision by Sumitomo's joint venture manufacturing standards, this 2014 SH80-6 delivers robust performance through its Isuzu AU-4LE2X engine, generating 40kW at 2000rpm from a 2.179L displacement. Hydraulic excellence defines this 8-ton excavator, featuring a 29.4 MPa working circuit and main overflow system that powers a 56.4kN bucket digging force and 39.3kN arm digging force—critical metrics for demanding excavation tasks.
Operating weight of 7,460kg provides optimal stability while maintaining a compact footprint with 2,320mm transport width. The 0.38m³ backhoe bucket paired with a 1,690mm rod length achieves a maximum digging depth of 4,050mm and an impressive 6,460mm working radius. Rotation speed of 9.9rpm ensures efficient cycle times across varied jobsite conditions.
- Isuzu AU-4LE2X diesel engine: 40kW rated power
- High-pressure hydraulics: 29.4 MPa system pressure
- Maximum digging height: 6,950mm
- Travel speeds: 5.1/3.2 km/h for versatile mobility
- Fuel capacity: 120L for extended operation
- Location: Hunan Province, China
Built for reliability in the compact excavator segment, this SH80-6 represents proven Japanese engineering ada
| Specifications | Value |
|---|---|
| No. | 1027030 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7460 |
| Bucket capacity (m³) | 0.38 |
| Rod length (mm) | 1690 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AU-4LE2X |
| Rated power (kw/rpm) | 40/2000 |
| Displacement (L) | 2.179 |
| Rotation speed (rpm) | 9.9 |
| Climbing ability (%) | |
| Bucket digging force (kN) | 56.4 |
| Rod digging force (kN) | 39.3 |
| Travel speed (km/h) | 5.1/3.2 |
| Main overflow set pressure (Mpa) | 29.4 |
| Type of walking hydraulic motor | |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 51 |
| Hydraulic System (L) | 96 |
| Total transport length (mm) | 6090 |
| Total transport width (mm) | 2320 |
| Total transport height (mm) | 2750 |
| Counterweight ground clearance (mm) | 750 |
| Minimum turning radius of front working device (mm) | 1980 |
| Back end turning radius (mm) | 1750 |
| Total track length (mm) | 2845 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2320 |
| Track ground length (mm) | 2210 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4050 |
| Maximum excavation height (mm) | 6950 |
| Maximum unloading height (mm) | 4890 |
