Product Description
Proven in demanding applications worldwide, this 2016 Sumitomo SH80-6 excavator delivers the brand reliability contractors depend on when buying used machinery. Operating at 8 tons with a 7,460 kg working weight, this compact performer combines an Isuzu AU-4LE2X engine (40 kW at 2,000 rpm) with precision hydraulics rated at 29.4 MPa for consistent production across job sites.
Sumitomo's joint venture engineering ensures parts availability remains strong in global markets—a critical advantage reducing downtime and protecting your investment. With a 6,460 mm maximum digging radius and 4,050 mm digging depth, this unit handles trenching, grading, and loading with a 0.38 m³ backhoe bucket backed by 56.4 kN digging force.
- Isuzu AU-4LE2X diesel engine: 2.179L displacement, field-proven durability
- Compact transport dimensions: 6,090 mm length, fits standard trailers
- Strong resale retention: Sumitomo's reputation maintains value
- Currently located in Dongguan, Guangdong—ready for inspection
Buy with confidence from a manufacturer whose parts network and engineering support outlast the competition.
| Specifications | Value |
|---|---|
| No. | 1023640 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7460 |
| Bucket capacity (m³) | 0.38 |
| Rod length (mm) | 1690 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AU-4LE2X |
| Rated power (kw/rpm) | 40/2000 |
| Displacement (L) | 2.179 |
| Rotation speed (rpm) | 9.9 |
| Climbing ability (%) | |
| Bucket digging force (kN) | 56.4 |
| Rod digging force (kN) | 39.3 |
| Travel speed (km/h) | 5.1/3.2 |
| Main overflow set pressure (Mpa) | 29.4 |
| Type of walking hydraulic motor | |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 51 |
| Hydraulic System (L) | 96 |
| Total transport length (mm) | 6090 |
| Total transport width (mm) | 2320 |
| Total transport height (mm) | 2750 |
| Counterweight ground clearance (mm) | 750 |
| Minimum turning radius of front working device (mm) | 1980 |
| Back end turning radius (mm) | 1750 |
| Total track length (mm) | 2845 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2320 |
| Track ground length (mm) | 2210 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4050 |
| Maximum excavation height (mm) | 6950 |
| Maximum unloading height (mm) | 4890 |
