Product Description
Strengthen your fleet capacity with this 2019 Sumitomo SH80-6, an 8-ton excavator built for contractors who need reliable backup power during peak project seasons. Powered by an Isuzu AU-4LE2X engine delivering 40kW at 2000 rpm, this compact machine tackles trenching, grading, and utility work without compromising performance. Its 0.38 m³ bucket and 1690mm rod length provide versatile reach for confined jobsites, while 56.4 kN bucket digging force handles demanding soil conditions efficiently.
- Working Weight: 7,460 kg – maneuverable yet stable
- Maximum Digging Depth: 4,050 mm for deep excavation tasks
- Maximum Digging Radius: 6,460 mm extends operational range
- Compact Dimensions: 6,090 mm (L) × 2,320 mm (W) – fits standard transport
- Hydraulic Efficiency: 29.4 MPa system pressure ensures responsive control
- Fuel Capacity: 120L tank supports extended shifts
Currently located in Hunan, this joint venture-manufactured unit integrates seamlessly into existing Sumitomo or mixed-brand fleets. Add proven Japanese engineering to your rotation and keep projects
| Specifications | Value |
|---|---|
| No. | 1028705 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7460 |
| Bucket capacity (m³) | 0.38 |
| Rod length (mm) | 1690 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AU-4LE2X |
| Rated power (kw/rpm) | 40/2000 |
| Displacement (L) | 2.179 |
| Rotation speed (rpm) | 9.9 |
| Climbing ability (%) | |
| Bucket digging force (kN) | 56.4 |
| Rod digging force (kN) | 39.3 |
| Travel speed (km/h) | 5.1/3.2 |
| Main overflow set pressure (Mpa) | 29.4 |
| Type of walking hydraulic motor | |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 51 |
| Hydraulic System (L) | 96 |
| Total transport length (mm) | 6090 |
| Total transport width (mm) | 2320 |
| Total transport height (mm) | 2750 |
| Counterweight ground clearance (mm) | 750 |
| Minimum turning radius of front working device (mm) | 1980 |
| Back end turning radius (mm) | 1750 |
| Total track length (mm) | 2845 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2320 |
| Track ground length (mm) | 2210 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4050 |
| Maximum excavation height (mm) | 6950 |
| Maximum unloading height (mm) | 4890 |
