Product Description
Built for compact job sites and precision excavation work, this 2021 Sumitomo SH80-6 delivers reliable performance across digging, grading, and material handling applications. Powered by an Isuzu AU-4LE2X engine producing 40kW at 2000rpm, this 8-ton excavator combines proven Japanese engineering with the maneuverability needed for urban construction and utility projects.
Equipped with a 0.38m³ backhoe bucket and 1690mm rod length, the machine offers a maximum digging depth of 4050mm and reach of 6460mm—ideal for trenching, foundation work, and site preparation. Bucket digging force reaches 56.4kN while rod force delivers 39.3kN, providing the breakout power required for demanding soil conditions.
Key specifications include:
- Working weight: 7460kg with stable 2320mm track width
- Compact transport dimensions: 6090mm length × 2750mm height
- Hydraulic system operating at 29.4Mpa with 96L total capacity
- 120L fuel tank for extended operation between refills
- 9.9rpm rotation speed for efficient positioning
Currently located in Zhejiang, this site-ready excavator requires minimal setup and is prepared for immediate deployment on your next project.
| Specifications | Value |
|---|---|
| No. | 1018183 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7460 |
| Bucket capacity (m³) | 0.38 |
| Rod length (mm) | 1690 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AU-4LE2X |
| Rated power (kw/rpm) | 40/2000 |
| Displacement (L) | 2.179 |
| Rotation speed (rpm) | 9.9 |
| Climbing ability (%) | |
| Bucket digging force (kN) | 56.4 |
| Rod digging force (kN) | 39.3 |
| Travel speed (km/h) | 5.1/3.2 |
| Main overflow set pressure (Mpa) | 29.4 |
| Type of walking hydraulic motor | |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 51 |
| Hydraulic System (L) | 96 |
| Total transport length (mm) | 6090 |
| Total transport width (mm) | 2320 |
| Total transport height (mm) | 2750 |
| Counterweight ground clearance (mm) | 750 |
| Minimum turning radius of front working device (mm) | 1980 |
| Back end turning radius (mm) | 1750 |
| Total track length (mm) | 2845 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2320 |
| Track ground length (mm) | 2210 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4050 |
| Maximum excavation height (mm) | 6950 |
| Maximum unloading height (mm) | 4890 |
