Product Description
Compact power meets legendary Swedish engineering in this 2016 Volvo EC14 mini excavator, currently located in Maoming, Guangdong. Built for precision work in confined spaces, this 1.5-ton machine delivers reliable performance backed by Volvo's reputation for durability and long-term value retention. Powered by a proven Mitsubishi L3E three-cylinder engine producing 14kW at 2200 rpm, this joint venture model combines international quality standards with practical serviceability.
Key specifications include:
- Maximum digging depth of 2015mm with 3415mm excavation radius
- Compact transport dimensions: 3410mm length × 980mm width × 2190mm height
- Efficient hydraulic system: 32 l/min main pump flow at 16 Mpa pressure
- 0.03m³ backhoe bucket capacity ideal for utility and landscaping applications
Choosing Volvo in the used equipment market means investing in a brand with extensive parts networks across China and proven resale strength. With straightforward maintenance requirements—3.6L engine oil, 36L hydraulic capacity—and robust construction, this EC14 represents a smart acquisition for contractors prioritizing uptime and long-term asset value over initial purchase price.
| Specifications | Value |
|---|---|
| No. | 1006195 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1530 |
| Bucket capacity (m³) | 0.03 |
| Boom length (mm) | 1630 |
| Rod length (mm) | 900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi L3E |
| Rated power (kw/rpm) | 14/2200 |
| Maximum torque (N.m) | 54/1850 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 0.95 |
| Rotation speed (rpm) | 9 |
| Travel speed (km/h) | 2 |
| Main overflow set pressure (Mpa) | 16 |
| Maximum flow of main pump (l/min) | 32 |
| Fuel Tank (L) | 21 |
| Engine Oil changes (L) | 3.6 |
| Coolant (L) | 4.5 |
| Hydraulic System (L) | 36 |
| Total transport length (mm) | 3410 |
| Total transport width (mm) | 980 |
| Total transport height (mm) | 2190 |
| Full cab height (mm) | 2190 |
| Counterweight ground clearance (mm) | 460 |
| Minimum ground clearance (mm) | 210 |
| Back end turning radius (mm) | 1090 |
| Track gauge (mm) | 760 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1045 |
| Maximum digging depth (mm) | 2015 |
| Maximum excavation height (mm) | 3075 |
| Maximum unloading height (mm) | 2255 |
| Maximum vertical digging depth (mm) | 1070 |
| Maximum excavation radius of stop surface (mm) | 3415 |
