Product Description
Compact power meets legendary Volvo engineering in this 2016 EC14 mini excavator, currently located in Guizhou. Weighing just 1,530 kg with a 0.03 m³ bucket capacity, this 1-ton machine delivers precision performance for tight urban sites, landscaping projects, and utility installations. Powered by a reliable Mitsubishi L3E engine producing 14 kW at 2,200 rpm, it combines efficient fuel consumption with robust hydraulic force—32 l/min main pump flow and 16 Mpa system pressure ensure responsive digging in demanding conditions.
Volvo's reputation for durability translates directly into lower ownership costs. Parts availability remains excellent across global markets, protecting your investment against downtime. The brand's strong resale value means this EC14 retains its worth far better than competing models. With a maximum digging depth of 2,015 mm and excavation radius of 3,415 mm, it handles foundation work, trenching, and material handling with authority.
- Mitsubishi L3E 3-cylinder diesel engine (0.95L displacement)
- Compact transport dimensions: 3,410 mm × 980 mm × 2,190 mm
- 9 rpm rotation speed for smooth positioning
- 230 mm track plates deliver excellent stability
- 21L fuel t
| Specifications | Value |
|---|---|
| No. | 1016528 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1530 |
| Bucket capacity (m³) | 0.03 |
| Boom length (mm) | 1630 |
| Rod length (mm) | 900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi L3E |
| Rated power (kw/rpm) | 14/2200 |
| Maximum torque (N.m) | 54/1850 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 0.95 |
| Rotation speed (rpm) | 9 |
| Travel speed (km/h) | 2 |
| Main overflow set pressure (Mpa) | 16 |
| Maximum flow of main pump (l/min) | 32 |
| Fuel Tank (L) | 21 |
| Engine Oil changes (L) | 3.6 |
| Coolant (L) | 4.5 |
| Hydraulic System (L) | 36 |
| Total transport length (mm) | 3410 |
| Total transport width (mm) | 980 |
| Total transport height (mm) | 2190 |
| Full cab height (mm) | 2190 |
| Counterweight ground clearance (mm) | 460 |
| Minimum ground clearance (mm) | 210 |
| Back end turning radius (mm) | 1090 |
| Track gauge (mm) | 760 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1045 |
| Maximum digging depth (mm) | 2015 |
| Maximum excavation height (mm) | 3075 |
| Maximum unloading height (mm) | 2255 |
| Maximum vertical digging depth (mm) | 1070 |
| Maximum excavation radius of stop surface (mm) | 3415 |
