Product Description
Engineered with precision-grade hydraulics delivering 16 MPa main overflow pressure and 32 L/min pump flow, this 2016 Volvo EC14 mini excavator exemplifies compact power. The Mitsubishi L3E engine generates 14 kW at 2200 rpm with 54 N·m peak torque, providing reliable performance for confined jobsites. At just 1,530 kg working weight with 0.03 m³ bucket capacity, this machine balances maneuverability with productive digging capability.
Key technical specifications include:
- Maximum digging depth: 2,015 mm with 3,415 mm excavation radius
- Compact dimensions: 3,410 mm length × 980 mm width for tight access
- 9 rpm rotation speed with 1,090 mm rear turning radius
- 460 mm counterweight clearance minimizes ground disturbance
- 36-liter hydraulic system capacity ensures thermal stability
- 230 mm track plates on 760 mm gauge for optimal ground pressure distribution
Currently located in Luzhou, Sichuan, this joint venture/import unit represents Volvo's commitment to robust mini excavator design backed by proven Japanese engine technology.
| Specifications | Value |
|---|---|
| No. | 1016838 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1530 |
| Bucket capacity (m³) | 0.03 |
| Boom length (mm) | 1630 |
| Rod length (mm) | 900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi L3E |
| Rated power (kw/rpm) | 14/2200 |
| Maximum torque (N.m) | 54/1850 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 0.95 |
| Rotation speed (rpm) | 9 |
| Travel speed (km/h) | 2 |
| Main overflow set pressure (Mpa) | 16 |
| Maximum flow of main pump (l/min) | 32 |
| Fuel Tank (L) | 21 |
| Engine Oil changes (L) | 3.6 |
| Coolant (L) | 4.5 |
| Hydraulic System (L) | 36 |
| Total transport length (mm) | 3410 |
| Total transport width (mm) | 980 |
| Total transport height (mm) | 2190 |
| Full cab height (mm) | 2190 |
| Counterweight ground clearance (mm) | 460 |
| Minimum ground clearance (mm) | 210 |
| Back end turning radius (mm) | 1090 |
| Track gauge (mm) | 760 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1045 |
| Maximum digging depth (mm) | 2015 |
| Maximum excavation height (mm) | 3075 |
| Maximum unloading height (mm) | 2255 |
| Maximum vertical digging depth (mm) | 1070 |
| Maximum excavation radius of stop surface (mm) | 3415 |
