Product Description
Equipped with a Mitsubishi L3E engine, this 2019 Volvo EC14 mini excavator delivers 14 kW of power at 2200 rpm, ensuring reliable performance. Featuring a main pump with a maximum flow of 32 l/min and a main overflow set pressure of 16 Mpa, the hydraulic system is designed for precision and efficiency. With a working weight of 1530 kg and a bucket capacity of 0.03 m³, this compact machine is ideal for tight spaces and detailed work. The boom length of 1630 mm and rod length of 900 mm provide a maximum digging depth of 2015 mm and a maximum excavation height of 3075 mm, enhancing its versatility on various job sites.
- Engine: Mitsubishi L3E, 3-cylinder, 0.95 L displacement
- Hydraulics: Main pump flow 32 l/min, main overflow set pressure 16 Mpa
- Dimensions: Total transport length 3410 mm, width 980 mm, height 2190 mm
- Performance: Maximum digging depth 2015 mm, maximum excavation height 3075 mm
| Specifications | Value |
|---|---|
| No. | 1000892 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1530 |
| Bucket capacity (m³) | 0.03 |
| Boom length (mm) | 1630 |
| Rod length (mm) | 900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi L3E |
| Rated power (kw/rpm) | 14/2200 |
| Maximum torque (N.m) | 54/1850 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 0.95 |
| Rotation speed (rpm) | 9 |
| Travel speed (km/h) | 2 |
| Main overflow set pressure (Mpa) | 16 |
| Maximum flow of main pump (l/min) | 32 |
| Fuel Tank (L) | 21 |
| Engine Oil changes (L) | 3.6 |
| Coolant (L) | 4.5 |
| Hydraulic System (L) | 36 |
| Total transport length (mm) | 3410 |
| Total transport width (mm) | 980 |
| Total transport height (mm) | 2190 |
| Full cab height (mm) | 2190 |
| Counterweight ground clearance (mm) | 460 |
| Minimum ground clearance (mm) | 210 |
| Back end turning radius (mm) | 1090 |
| Track gauge (mm) | 760 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1045 |
| Maximum digging depth (mm) | 2015 |
| Maximum excavation height (mm) | 3075 |
| Maximum unloading height (mm) | 2255 |
| Maximum vertical digging depth (mm) | 1070 |
| Maximum excavation radius of stop surface (mm) | 3415 |
