Product Description
Engineered with precision, this 2016 Volvo EC20 compact excavator delivers exceptional performance through its robust Mitsubishi L3E three-cylinder engine, generating 14kW at 2200 rpm with 54 N.m maximum torque. The advanced hydraulic system operates at 21 Mpa main overflow pressure with a 43 l/min pump flow rate, ensuring responsive control and efficient power delivery across all functions.
Built on joint venture/import manufacturing standards, this 2-ton machine combines a 1,780 kg working weight with impressive reach capabilities: 4,010 mm maximum excavation radius, 2,570 mm digging depth, and 3,750 mm excavation height. The 1,900 mm boom and 1,050 mm arm configuration optimize versatility in confined spaces while maintaining structural integrity.
- Compact dimensions: 3,780 mm length × 1,200 mm width × 2,270 mm height
- Low ground pressure: 28.4 Kpa for minimal surface disturbance
- 10 rpm rotation speed with 1,160 mm rear turning radius
- 4.7 km/h travel speed for efficient site mobility
- Currently located in Hechi, Guangxi
Traditional power architecture ensures reliability and straightforward maintenance, backed by Volvo's engineering heritage in construction equi
| Specifications | Value |
|---|---|
| No. | 998226 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 1780 |
| Bucket capacity (m³) | 0.05 |
| Boom length (mm) | 1900 |
| Rod length (mm) | 1050 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi L3E |
| Rated power (kw/rpm) | 14/2200 |
| Maximum torque (N.m) | 54/1850 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 0.95 |
| Ground specific pressure (Kpa) | 28.4 |
| Rotation speed (rpm) | 10 |
| Travel speed (km/h) | 4.7 |
| Main overflow set pressure (Mpa) | 21 |
| Maximum flow of main pump (l/min) | 43 |
| Fuel Tank (L) | 21 |
| Engine Oil changes (L) | 3.6 |
| Coolant (L) | 4.5 |
| Hydraulic System (L) | 23 |
| Total transport length (mm) | 3780 |
| Total transport width (mm) | 1200 |
| Total transport height (mm) | 2270 |
| Full cab height (mm) | 2270 |
| Counterweight ground clearance (mm) | 470 |
| Back end turning radius (mm) | 1160 |
| Track gauge (mm) | 950 |
| Track plate width (mm) | 250 |
| Track ground length (mm) | 1240 |
| Maximum digging depth (mm) | 2570 |
| Maximum excavation height (mm) | 3750 |
| Maximum unloading height (mm) | 2670 |
| Maximum vertical digging depth (mm) | 1580 |
| Maximum excavation radius of stop surface (mm) | 4010 |
