Product Description
Maximize your return on investment with this 2019 Volvo EC20 compact excavator, currently available in Shanghai. Delivering professional-grade performance at a fraction of new equipment costs, this 2-ton machine combines Volvo's renowned build quality with practical specifications for tight-access projects. Powered by a reliable Mitsubishi L3E engine producing 14kW at 2200 rpm, it offers the efficiency and durability your operation demands without the premium price tag of new machinery.
Key specifications include:
- Working weight: 1,780 kg with 0.05 m³ bucket capacity
- Maximum digging depth: 2,570 mm; excavation radius: 4,010 mm
- Compact transport dimensions: 3,780 mm (L) × 1,200 mm (W) × 2,270 mm (H)
- Hydraulic system: 43 l/min main pump flow at 21 Mpa pressure
- Fuel-efficient 21L tank with 4.7 km/h travel speed
Backed by joint venture manufacturing standards and imported components, this EC20 represents smart capital allocation for contractors seeking proven reliability without new equipment depreciation. Ideal for urban construction, landscaping, and utility work where maneuverability matters.
| Specifications | Value |
|---|---|
| No. | 1007658 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 1780 |
| Bucket capacity (m³) | 0.05 |
| Boom length (mm) | 1900 |
| Rod length (mm) | 1050 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi L3E |
| Rated power (kw/rpm) | 14/2200 |
| Maximum torque (N.m) | 54/1850 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 0.95 |
| Ground specific pressure (Kpa) | 28.4 |
| Rotation speed (rpm) | 10 |
| Travel speed (km/h) | 4.7 |
| Main overflow set pressure (Mpa) | 21 |
| Maximum flow of main pump (l/min) | 43 |
| Fuel Tank (L) | 21 |
| Engine Oil changes (L) | 3.6 |
| Coolant (L) | 4.5 |
| Hydraulic System (L) | 23 |
| Total transport length (mm) | 3780 |
| Total transport width (mm) | 1200 |
| Total transport height (mm) | 2270 |
| Full cab height (mm) | 2270 |
| Counterweight ground clearance (mm) | 470 |
| Back end turning radius (mm) | 1160 |
| Track gauge (mm) | 950 |
| Track plate width (mm) | 250 |
| Track ground length (mm) | 1240 |
| Maximum digging depth (mm) | 2570 |
| Maximum excavation height (mm) | 3750 |
| Maximum unloading height (mm) | 2670 |
| Maximum vertical digging depth (mm) | 1580 |
| Maximum excavation radius of stop surface (mm) | 4010 |
