Product Description
Engineered with precision, this 2020 Volvo EC20 compact excavator delivers exceptional performance through its robust Mitsubishi L3E 3-cylinder engine, generating 14 kW at 2200 rpm with 54 N.m maximum torque. Hydraulic efficiency defines this machine—featuring a 43 l/min main pump capacity and 21 Mpa overflow pressure, ensuring responsive control across all digging operations. Weighing just 1,780 kg with a 0.05 m³ bucket capacity, this 2-ton excavator excels in confined urban sites and precision grading work.
- Maximum Digging Depth: 2,570 mm with 4,010 mm excavation radius
- Compact Dimensions: 3,780 mm length × 1,200 mm width—ideal for tight access
- Superior Mobility: 4.7 km/h travel speed, 1,160 mm rear turning radius
- Low Ground Pressure: 28.4 kPa minimizes surface damage
- Service-Friendly Design: 21 L fuel tank, 23 L hydraulic system capacity
Currently located in Huizhou, Guangdong, this Volvo-engineered machine represents proven joint venture manufacturing quality. Contact Fair Trade Machinery for detailed specifications and export arrangements.
| Specifications | Value |
|---|---|
| No. | 1016006 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 1780 |
| Bucket capacity (m³) | 0.05 |
| Boom length (mm) | 1900 |
| Rod length (mm) | 1050 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi L3E |
| Rated power (kw/rpm) | 14/2200 |
| Maximum torque (N.m) | 54/1850 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 0.95 |
| Ground specific pressure (Kpa) | 28.4 |
| Rotation speed (rpm) | 10 |
| Travel speed (km/h) | 4.7 |
| Main overflow set pressure (Mpa) | 21 |
| Maximum flow of main pump (l/min) | 43 |
| Fuel Tank (L) | 21 |
| Engine Oil changes (L) | 3.6 |
| Coolant (L) | 4.5 |
| Hydraulic System (L) | 23 |
| Total transport length (mm) | 3780 |
| Total transport width (mm) | 1200 |
| Total transport height (mm) | 2270 |
| Full cab height (mm) | 2270 |
| Counterweight ground clearance (mm) | 470 |
| Back end turning radius (mm) | 1160 |
| Track gauge (mm) | 950 |
| Track plate width (mm) | 250 |
| Track ground length (mm) | 1240 |
| Maximum digging depth (mm) | 2570 |
| Maximum excavation height (mm) | 3750 |
| Maximum unloading height (mm) | 2670 |
| Maximum vertical digging depth (mm) | 1580 |
| Maximum excavation radius of stop surface (mm) | 4010 |
