Product Description
Available now in Shanghai, this 2020 Volvo EC20 mini excavator eliminates factory lead times and puts 2-ton lifting capacity on your jobsite immediately. Powered by a proven Mitsubishi L3E engine delivering 14 kW at 2200 rpm, this compact machine combines joint venture build quality with fast deployment logistics. With a working weight of just 1,780 kg and transport dimensions of 3,780 mm length by 1,200 mm width, it ships efficiently to ports worldwide.
- Immediate Availability: Shanghai stock means rapid container loading and export processing
- Compact Logistics: 1.2 m width navigates standard doorways and containers without disassembly
- Performance Specs: 2,570 mm dig depth, 4,010 mm reach, 43 L/min hydraulic flow
- Reliable Power: 3-cylinder Mitsubishi engine with 54 N·m torque at 1,850 rpm
- Site-Ready: 0.05 m³ backhoe bucket, 4.7 km/h travel speed, 10 rpm swing
Skip months of factory queues. This EC20 ships from Shanghai within days, cutting your project timeline and getting operators productive faster. Ideal for urban construction, landscaping, and utility work requiring quick mobilizat
| Specifications | Value |
|---|---|
| No. | 1017566 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 1780 |
| Bucket capacity (m³) | 0.05 |
| Boom length (mm) | 1900 |
| Rod length (mm) | 1050 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi L3E |
| Rated power (kw/rpm) | 14/2200 |
| Maximum torque (N.m) | 54/1850 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 0.95 |
| Ground specific pressure (Kpa) | 28.4 |
| Rotation speed (rpm) | 10 |
| Travel speed (km/h) | 4.7 |
| Main overflow set pressure (Mpa) | 21 |
| Maximum flow of main pump (l/min) | 43 |
| Fuel Tank (L) | 21 |
| Engine Oil changes (L) | 3.6 |
| Coolant (L) | 4.5 |
| Hydraulic System (L) | 23 |
| Total transport length (mm) | 3780 |
| Total transport width (mm) | 1200 |
| Total transport height (mm) | 2270 |
| Full cab height (mm) | 2270 |
| Counterweight ground clearance (mm) | 470 |
| Back end turning radius (mm) | 1160 |
| Track gauge (mm) | 950 |
| Track plate width (mm) | 250 |
| Track ground length (mm) | 1240 |
| Maximum digging depth (mm) | 2570 |
| Maximum excavation height (mm) | 3750 |
| Maximum unloading height (mm) | 2670 |
| Maximum vertical digging depth (mm) | 1580 |
| Maximum excavation radius of stop surface (mm) | 4010 |
