Product Description
Engineered with precision for compact jobsites, this 2020 Volvo EC20 mini excavator delivers exceptional performance through proven Mitsubishi L3E power. Rated at 14 kW at 2200 rpm with 54 N.m maximum torque, the 3-cylinder diesel engine provides reliable output for demanding excavation tasks. The hydraulic system operates at 21 Mpa with a 43 l/min main pump flow, ensuring responsive digging and lifting capabilities across its 4010 mm maximum excavation radius.
- Working weight: 1780 kg with 0.05 m³ backhoe bucket capacity
- Maximum digging depth: 2570 mm; vertical depth: 1580 mm
- Compact transport dimensions: 3780 × 1200 × 2270 mm
- Superior maneuverability: 1160 mm rear turning radius, 950 mm track gauge
- Ground pressure: 28.4 Kpa for minimal surface disturbance
- Travel speed: 4.7 km/h with 10 rpm rotation speed
Currently located in Hangzhou, Zhejiang, this joint venture-manufactured unit combines Volvo's engineering standards with practical serviceability. Comprehensive fluid capacities include 21 L fuel, 23 L hydraulic oil, and 4.5 L coolant for extended operational intervals.
| Specifications | Value |
|---|---|
| No. | 1032160 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 1780 |
| Bucket capacity (m³) | 0.05 |
| Boom length (mm) | 1900 |
| Rod length (mm) | 1050 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi L3E |
| Rated power (kw/rpm) | 14/2200 |
| Maximum torque (N.m) | 54/1850 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 0.95 |
| Ground specific pressure (Kpa) | 28.4 |
| Rotation speed (rpm) | 10 |
| Travel speed (km/h) | 4.7 |
| Main overflow set pressure (Mpa) | 21 |
| Maximum flow of main pump (l/min) | 43 |
| Fuel Tank (L) | 21 |
| Engine Oil changes (L) | 3.6 |
| Coolant (L) | 4.5 |
| Hydraulic System (L) | 23 |
| Total transport length (mm) | 3780 |
| Total transport width (mm) | 1200 |
| Total transport height (mm) | 2270 |
| Full cab height (mm) | 2270 |
| Counterweight ground clearance (mm) | 470 |
| Back end turning radius (mm) | 1160 |
| Track gauge (mm) | 950 |
| Track plate width (mm) | 250 |
| Track ground length (mm) | 1240 |
| Maximum digging depth (mm) | 2570 |
| Maximum excavation height (mm) | 3750 |
| Maximum unloading height (mm) | 2670 |
| Maximum vertical digging depth (mm) | 1580 |
| Maximum excavation radius of stop surface (mm) | 4010 |
