Product Description
Discover the 2016 Volvo EC250D, a premium excavator now available in Guangxi, China. This machine is well-maintained and comes with all necessary documentation, ensuring a seamless transaction. Ideal for construction and excavation projects, the EC250D offers reliable performance and durability. With its robust design and advanced features, this excavator is ready to meet the demands of your next project.
- Year: 2016
- Brand: Volvo
- Model: EC250D
- Location: Guangxi, China
- All documentation included
| Specifications | Value |
|---|---|
| No. | 1119271 |
| Tonnage (tons) | 25 |
| Working weight (kg) | 24600 - 28000 |
| Bucket capacity (m³) | 0.48 - 1.85 |
| Country of origin | Korea |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | D7E |
| Rated power (kw/rpm) | 138/1800 |
| Cylinder diameter × stroke (mm) | 108*130 |
| Maximum torque (N.m) | 870 / 1 350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.1 |
| Rotation speed (rpm) | 11.9 |
| Bucket digging force (kN) | 152 |
| Rod digging force (kN) | 115 |
| Maximum tractive force (kN) | 217 |
| Travel speed (km/h) | 3.5/5.5 |
| Turning torque (Nm) | 91.6 |
| Maximum flow of main pump (l/min) | 2 x 240 |
| Traveling Hydraulic Circuit (Mpa) | 36.3 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Fuel Tank (L) | 470 |
| Hydraulic Tank (L) | 195 |
| Engine Oil changes (L) | 32 |
| Coolant (L) | 41 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 10260 |
| Total transport width (mm) | 2990 |
| Full cab height (mm) | 3020 |
| Counterweight ground clearance (mm) | 1080 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 3070 |
| Onboard width (mm) | 2890 |
| Total track length (mm) | 4450 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10260 |
| Maximum digging depth (mm) | 6980 |
| Maximum excavation height (mm) | 9690 |
| Maximum unloading height (mm) | 6 800 |
