HOME>>Volvo>>Volvo EC250D

2020 Volvo EC250D

1/6
Buy Volvo EC250D Used Excavator / 1
Buy Volvo EC250D Used Excavator / 2
Buy Volvo EC250D Used Excavator / 3
Buy Volvo EC250D Used Excavator / 4
Buy Volvo EC250D Used Excavator / 5
Buy Volvo EC250D Used Excavator / 6

Product Description

2020 Volvo EC250D excavator available from Zhejiang, China. This 25-ton class machine represents Volvo's proven D-Series design, offering reliable performance for medium to heavy-duty earthmoving operations. The EC250D features Volvo's fuel-efficient engine technology and robust hydraulic system, designed for demanding construction and excavation applications.

Key specifications:

  • Operating weight: approximately 25,000 kg
  • Volvo D6E engine with reduced emissions
  • Advanced hydraulics for precise control
  • Spacious ROPS/FOPS certified cab
  • Well-maintained unit from Zhejiang region

This EC250D combines productivity with operator comfort, making it suitable for site development, infrastructure projects, and material handling. The machine's four-year operational history indicates moderate use with significant service life remaining. Ideal for contractors seeking proven Volvo engineering at competitive pricing.

SpecificationsValue
No.1085425
Tonnage (tons)25
Working weight (kg)24600 - 28000
Bucket capacity (m³)0.48 - 1.85
Country of originKorea
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeD7E
Rated power (kw/rpm)138/1800
Cylinder diameter × stroke (mm)108*130
Maximum torque (N.m)870 / 1 350
Number of cylinders (PCS)6
Displacement (L)7.1
Rotation speed (rpm)11.9
Bucket digging force (kN)152
Rod digging force (kN)115
Maximum tractive force (kN)217
Travel speed (km/h)3.5/5.5
Turning torque (Nm)91.6
Maximum flow of main pump (l/min)2 x 240
Traveling Hydraulic Circuit (Mpa)36.3
Control Hydraulic Circuit (Mpa)3.9
Fuel Tank (L)470
Hydraulic Tank (L)195
Engine Oil changes (L)32
Coolant (L)41
Hydraulic System (L)400
Total transport length (mm)10260
Total transport width (mm)2990
Full cab height (mm)3020
Counterweight ground clearance (mm)1080
Minimum ground clearance (mm)470
Back end turning radius (mm)3070
Onboard width (mm)2890
Total track length (mm)4450
Track gauge (mm)2390
Track plate width (mm)600
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)9
Number of track plates (single side) (PCS)49
Maximum digging radius (mm)10260
Maximum digging depth (mm)6980
Maximum excavation height (mm)9690
Maximum unloading height (mm)6 800
see more

Overview

No.1085425

Brand Name:

Volvo

Model Number:

EC250D

Year:

2020

Location:

Zhejiang China

Pub Date
