Product Description
Built for immediate deployment, this 2019 Volvo EC30 compact excavator delivers reliable performance across confined jobsites in 浙江丽水. Powered by a proven Mitsubishi S3L2 engine generating 20kW at 2400 rpm, this 3-ton machine combines precision control with robust hydraulic power. The 62.1 L/min main pump flow ensures responsive operation for digging, grading, and demolition tasks without hesitation.
Compact dimensions—4370mm length, 1480mm width—allow access to restricted areas while maintaining a 4620mm maximum excavation radius. Dig to 2740mm depth or reach 4450mm height with the 2300mm boom and 1200mm arm configuration. The 0.07m³ backhoe bucket handles material efficiently, while the 1270mm rear turning radius enables work in tight quarters.
- Working weight: 3090.3kg for optimal stability
- Travel speed: 3.7 km/h for quick repositioning
- Ground clearance: 280mm minimum for varied terrain
- Fuel capacity: 49L for extended operation
- Hydraulic system: 46.5L capacity for consistent performance
Ready to work from day one, this joint venture/import machine brings Volvo engineering standards to your operation.
| Specifications | Value |
|---|---|
| No. | 1010268 |
| Tonnage (tons) | 3 |
| Working weight (kg) | 3090.3 |
| Bucket capacity (m³) | 0.07 |
| Boom length (mm) | 2300 |
| Rod length (mm) | 1200 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi S3L2 |
| Rated power (kw/rpm) | 20/2400 |
| Maximum torque (N.m) | 77/1600 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.3 |
| Ground specific pressure (Kpa) | 31 |
| Rotation speed (rpm) | 10 |
| Travel speed (km/h) | 3.7 |
| Maximum flow of main pump (l/min) | 62.1 |
| Fuel Tank (L) | 49 |
| Engine Oil changes (L) | 5.2 |
| Coolant (L) | 6 |
| Hydraulic System (L) | 46.5 |
| Total transport length (mm) | 4370 |
| Total transport width (mm) | 1480 |
| Total transport height (mm) | 2390 |
| Full cab height (mm) | 2390 |
| Counterweight ground clearance (mm) | 570 |
| Minimum ground clearance (mm) | 280 |
| Back end turning radius (mm) | 1270 |
| Track gauge (mm) | 1180 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1910 |
| Maximum digging depth (mm) | 2740 |
| Maximum excavation height (mm) | 4450 |
| Maximum unloading height (mm) | 3250 |
| Maximum vertical digging depth (mm) | 2150 |
| Maximum excavation radius of stop surface (mm) | 4620 |
