Product Description
Available now from our Jiangsu Changzhou facility, this 2016 Volvo EC380D delivers 38-ton performance without the factory wait. Powered by a robust 12.8L engine meeting US Tier 4i and EU Stage IIIB standards, this imported excavator combines proven reliability with immediate deployment to your project site.
Engineered for demanding applications, the EC380D features a maximum digging depth of 8,000mm and an impressive 11,520mm working radius. The backhoe configuration provides exceptional versatility, while digging forces up to 157.4kN (extra force mode) handle the toughest materials. Travel speeds of 3.4/5.53 km/h ensure efficient repositioning across your worksite.
- 38-ton class excavator with air-to-air cooling system
- Maximum digging depth: 8,000mm | Working radius: 11,520mm
- Track configuration: 2,740mm gauge, 5,180mm total length
- Multiple bucket widths available: 600/700/800/900mm options
- Ready for immediate shipment from Changzhou, Jiangsu
Skip months of factory lead times. This machine is inspected, serviced, and ready for fast deployment to your construction, mining, or infrastructure project.
| Specifications | Value |
|---|---|
| No. | 1027778 |
| Tonnage (tons) | 38 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Rod digging force (kN) | 144.4 (Standard) /157.4 (Extra force) |
| Travel speed (km/h) | 3.4/5.53 |
| Bulldozer lift or depth (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 11520 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 8000 |
| Total track length (mm) | 5180 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | Three teeth 600/700/800/900; Double tooth 600 |
| Total track width (mm) | 3340 |
| Displacement (L) | 12.8 |
| Working form | Air to air cooling, meet the US Tier4i and EU IIIB emission standards |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-145 x 1285 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-175 x 1750 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-160 x 1530 |
