Product Description
Discover the 2017 Volvo EC380D, a robust and reliable excavator currently available in Zhejiang, China. Designed for demanding construction and excavation tasks, this machine offers superior performance and durability. The EC380D is equipped with advanced technology to enhance productivity and efficiency, making it an excellent choice for large-scale projects. With its powerful engine and ergonomic design, operators can expect both comfort and control, ensuring optimal job site performance.
- Year: 2017
- Brand: Volvo
- Model: EC380D
- Location: Zhejiang, China
| Specifications | Value |
|---|---|
| No. | 1084366 |
| Tonnage (tons) | 38 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Rod digging force (kN) | 144.4 (Standard) /157.4 (Extra force) |
| Travel speed (km/h) | 3.4/5.53 |
| Bulldozer lift or depth (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 11520 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 8000 |
| Total track length (mm) | 5180 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | Three teeth 600/700/800/900; Double tooth 600 |
| Total track width (mm) | 3340 |
| Displacement (L) | 12.8 |
| Working form | Air to air cooling, meet the US Tier4i and EU IIIB emission standards |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-145 x 1285 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-175 x 1750 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-160 x 1530 |
