Product Description
Available now in Zhejiang Shaoxing, this 2018 Volvo EC380D delivers 38-ton excavation power without factory wait times. Powered by a robust 12.8L engine meeting US Tier 4i and EU Stage IIIB emission standards, this imported excavator combines proven reliability with regulatory compliance for immediate deployment to your site.
Performance specifications include 11,520mm maximum excavation radius and 8,000mm digging depth, supported by 144.4kN standard rod digging force (157.4kN with extra force option). Travel speeds reach 5.53 km/h for efficient repositioning across jobsites. The undercarriage features 5,180mm track length with 2,740mm gauge, accommodating bucket widths from 600-900mm to match your application requirements.
Skip months of lead time. This ready-to-work machine eliminates production delays and accelerates project timelines. Fast deployment from Shaoxing means reduced downtime and quicker ROI for contractors and operators across Asia-Pacific markets.
- Year: 2018 | Brand: Volvo | Model: EC380D
- Location: Zhejiang Shaoxing, China
- Tonnage: 38 tons | Engine: 12.8L diesel
- Digging Force: 144.4-157.4 kN
| Specifications | Value |
|---|---|
| No. | 1029766 |
| Tonnage (tons) | 38 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Rod digging force (kN) | 144.4 (Standard) /157.4 (Extra force) |
| Travel speed (km/h) | 3.4/5.53 |
| Bulldozer lift or depth (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 11520 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 8000 |
| Total track length (mm) | 5180 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | Three teeth 600/700/800/900; Double tooth 600 |
| Total track width (mm) | 3340 |
| Displacement (L) | 12.8 |
| Working form | Air to air cooling, meet the US Tier4i and EU IIIB emission standards |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-145 x 1285 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-175 x 1750 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-160 x 1530 |
