Product Description
Expand your fleet capacity with this 2017 Volvo EC480 Glory Edition excavator, currently positioned in Shandong and ready for immediate deployment. Built during Volvo's peak production year for the Chinese market, this heavy-duty crawler delivers the operational redundancy your high-volume projects demand. When your primary machines are maxed out or scheduled for maintenance, this unit steps in without workflow interruption.
- 48-ton operating weight handles large-scale earthmoving and demolition contracts
- Glory Edition spec package includes enhanced hydraulics and operator comfort features
- Proven D13 engine platform maintains fuel efficiency under extended duty cycles
- Shandong location enables cost-effective logistics throughout Asia-Pacific markets
- Six-year operational history provides verified maintenance intervals and parts availability
Fleet managers appreciate the EC480's compatibility with existing Volvo service protocols and operator training programs. Adding this machine eliminates the bottlenecks that cost you penalty clauses and client relationships. Contact Fair Trade Machinery for complete inspection reports and shipping quotes.
| Specifications | Value |
|---|---|
| No. | 1016933 |
| Tonnage (tons) | 48 |
| Working weight (kg) | 48162 |
| Bucket capacity (m³) | 2.6 |
| Boom length (mm) | 7000 |
| Rod length (mm) | 3000 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | VOLOV D13F |
| Rated power (kw/rpm) | 270/1800 |
| Maximum torque (N.m) | 1836/1400 |
| Rotation speed (rpm) | 8.9 |
| Bucket digging force (kN) | 284 |
| Rod digging force (kN) | 235 |
| Maximum tractive force (kN) | 333.4 |
| Travel speed (km/h) | 5.1/3.1 |
| Turning torque (Nm) | 166.3 |
| Maximum flow of main pump (l/min) | 2*355 |
| Traveling Hydraulic Circuit (Mpa) | 32.4 |
| Rotary Hydraulic Circuit (Mpa) | 25.8 |
| Working Hydraulic Circuit (Mpa) | 32.4 |
| Fuel Tank (L) | 680 |
| Engine Oil changes (L) | 55 |
| Coolant (L) | 60 |
| Total transport width (mm) | 3440 |
| Full cab height (mm) | 3280 |
| Counterweight ground clearance (mm) | 1210 |
| Minimum ground clearance (mm) | 515 |
| Back end turning radius (mm) | 3880 |
| Onboard width (mm) | 2990 |
| Total track length (mm) | 5470 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4470 |
| Maximum digging radius (mm) | 11817 |
| Maximum digging depth (mm) | 7478 |
