Product Description
Built for high-volume earthmoving and deep excavation, this 2015 Volvo EC700C delivers 70 tons of proven productivity from Hunan. Powered by a Volvo D16E EAE3 engine generating 336.5 kW at 1800 rpm, this machine tackles demanding projects with 356 kN bucket digging force and 332 kN arm digging force. Maximum digging depth reaches 7,605 mm with a reach extending to 12,600 mm—ideal for large-scale site development, quarry operations, and infrastructure work.
- Operating weight: 698,000–717,000 kg with bucket capacity up to 6.6 m³
- Dual variable displacement axial piston pumps maintain 34.3 MPa working pressure
- Travel speed: 4.6 km/h with 453 kN maximum tractive force
- 840 L fuel tank and 655 L hydraulic system capacity for extended shifts
- 70% grading capability and 6.7 rpm rotation speed for efficient positioning
Factory-spec hydraulics, robust undercarriage, and reliable joint-venture engineering make this EC700C ready for immediate deployment. Contact Fair Trade Machinery today for shipping options and current availability.
| Specifications | Value |
|---|---|
| No. | 1026634 |
| Tonnage (tons) | 70 |
| Working weight (kg) | 698000-717000 |
| Bucket capacity (m³) | 2.48-6.6 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo D16E EAE3 |
| Rated power (kw/rpm) | 336.5/1800 |
| Cylinder diameter × stroke (mm) | 114 x 165 |
| Maximum torque (N.m) | 2250/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 16.1 |
| Ground specific pressure (Kpa) | 75.5-102 |
| Rotation speed (rpm) | 6.7 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 356 |
| Rod digging force (kN) | 332 |
| Maximum tractive force (kN) | 453 |
| Travel speed (km/h) | 4.6/3 |
| Turning torque (Nm) | 225.6 |
| Rotary hydraulic motor type | Fixed displacement plunger hydraulic motor with mechanical brake |
| Type of walking hydraulic motor | Variable displacement axial piston hydraulic motor with mechanical brake |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Main pump type | Two variable displacement axial piston pumps |
| Working Hydraulic Circuit (Mpa) | 31.4/34.3 |
| Pilot pump flow (L/min) | 2 x 436 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 190 x 1.450 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 215 x 2.070 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 190 x 1.790 |
| Fuel Tank (L) | 840 |
| Hydraulic Tank (L) | 350 |
| Engine Oil changes (L) | 52 |
| Coolant (L) | 65 |
| Hydraulic System (L) | 655 |
| Total transport length (mm) | 12200 |
| Total transport width (mm) | 4286 |
| Total transport height (mm) | 4660-4855 |
| Full cab height (mm) | 3520 |
| Minimum turning radius of front working device (mm) | 5160-5480 |
| Back end turning radius (mm) | 4140 |
| Total track length (mm) | 5990 |
| Track plate width (mm) | 650/750/900 |
| Maximum digging radius (mm) | 11500-12600 |
| Maximum digging depth (mm) | 7100-7605 |
| Maximum excavation height (mm) | 10980-12490 |
| Maximum unloading height (mm) | 6960-8410 |
| Maximum vertical digging depth (mm) | 5065-6780 |
| Maximum excavation radius of stop surface (mm) | 11200-12335 |
