Product Description
Built for immediate deployment on demanding jobsites, this 2016 Volvo EC80D compact excavator delivers proven performance across digging, grading, and material handling operations. Powered by a reliable Volvo D3.4A engine producing 42kW at 2100 rpm with 243 N.m of torque, this 8-ton machine combines efficiency with robust capability. The 0.34 m³ backhoe bucket generates 49 kN of digging force, while the arm delivers 39 kN for precise trenching and excavation work.
Operational specifications include:
- Maximum digging depth of 4,100 mm and reach extending to 6,420 mm
- Maximum digging height of 7,130 mm for loading trucks and material placement
- Compact transport dimensions: 6,165 mm length × 2,300 mm width × 2,655 mm height
- Dual travel speeds (2.6/5.1 km/h) for efficient site mobility
- 450 mm track plates with 2,200 mm ground contact length for stability
Currently located in Hebei, this joint venture-manufactured excavator arrives site-ready with 7,450 kg working weight and a tight turning radius of 1,690 mm. Purpose-built for contractors requiring reliable performance in confined spaces and general construction applications.
| Specifications | Value |
|---|---|
| No. | 994254 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.34 |
| Country of origin | Korea |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo D3.4A |
| Rated power (kw/rpm) | 42/2100 |
| Maximum torque (N.m) | 243 |
| Bucket digging force (kN) | 49 |
| Rod digging force (kN) | 39 |
| Maximum tractive force (kN) | 65 |
| Travel speed (km/h) | 2.6/5.1 |
| Total transport length (mm) | 6165 |
| Total transport width (mm) | 2300 |
| Total transport height (mm) | 2655 |
| Full cab height (mm) | 2655 |
| Counterweight ground clearance (mm) | 755 |
| Minimum ground clearance (mm) | 400 |
| Minimum turning radius of front working device (mm) | 1690 |
| Back end turning radius (mm) | 1750 |
| Onboard width (mm) | 2280 |
| Total track length (mm) | 2850 |
| Track gauge (mm) | 1850 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2300 |
| Track ground length (mm) | 2200 |
| Maximum digging radius (mm) | 6420 |
| Maximum digging depth (mm) | 4100 |
| Maximum excavation height (mm) | 7130 |
| Maximum unloading height (mm) | 5150 |
| Maximum vertical digging depth (mm) | 3530 |
| Maximum excavation radius of stop surface (mm) | 6270 |
| Maximum effective digging depth (mm) | 3740 |
