Product Description
Available now in 四川泸州, the 2020 Volvo EC80D excavator is ready for immediate deployment to your site. With a working weight of 7450 kg and a bucket capacity of 0.34 m³, this compact yet powerful machine is ideal for a variety of construction and excavation tasks. Featuring a Volvo D3.4A engine, it delivers 42 kW at 2100 rpm, ensuring reliable performance. The EC80D boasts a maximum travel speed of 5.1 km/h, facilitating quick and efficient movement on-site. Its compact dimensions, including a total transport length of 6165 mm and width of 2300 mm, make it easy to maneuver in tight spaces. Skip the factory lead times and get your project moving with this versatile and robust excavator.
| Specifications | Value |
|---|---|
| No. | 1002923 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7450 |
| Bucket capacity (m³) | 0.34 |
| Country of origin | Korea |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo D3.4A |
| Rated power (kw/rpm) | 42/2100 |
| Maximum torque (N.m) | 243 |
| Bucket digging force (kN) | 49 |
| Rod digging force (kN) | 39 |
| Maximum tractive force (kN) | 65 |
| Travel speed (km/h) | 2.6/5.1 |
| Total transport length (mm) | 6165 |
| Total transport width (mm) | 2300 |
| Total transport height (mm) | 2655 |
| Full cab height (mm) | 2655 |
| Counterweight ground clearance (mm) | 755 |
| Minimum ground clearance (mm) | 400 |
| Minimum turning radius of front working device (mm) | 1690 |
| Back end turning radius (mm) | 1750 |
| Onboard width (mm) | 2280 |
| Total track length (mm) | 2850 |
| Track gauge (mm) | 1850 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2300 |
| Track ground length (mm) | 2200 |
| Maximum digging radius (mm) | 6420 |
| Maximum digging depth (mm) | 4100 |
| Maximum excavation height (mm) | 7130 |
| Maximum unloading height (mm) | 5150 |
| Maximum vertical digging depth (mm) | 3530 |
| Maximum excavation radius of stop surface (mm) | 6270 |
| Maximum effective digging depth (mm) | 3740 |
