Product Description
With a working weight of 2727 kg and powered by a robust Volvo D1.2 engine, this 2020 Volvo ECR28 excavator stands as a testament to durability and reliability. Located in 四川泸州, it features a 0.06 m³ bucket capacity, ideal for various construction tasks. Designed with a boom length of 2000 mm and rod length of 1050 mm, this machine ensures efficient performance on any job site.
- Rated power: 14.4 kW at 2200 rpm
- Maximum torque: 65.6 N.m at 1600 rpm
- Ground specific pressure: 33.1 Kpa
- Travel speed: 3.9 km/h
- Fuel tank capacity: 49 L
Built to last, the ECR28 has proven its worth with a maximum digging depth of 2380 mm and an excavation height of 3950 mm. Its compact design, with a total transport width of 1500 mm and height of 2440 mm, makes it easy to maneuver and transport. Trust in the enduring quality and performance of this Volvo excavator, a reliable workhorse for your fleet.
| Specifications | Value |
|---|---|
| No. | 995414 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 2727 |
| Bucket capacity (m³) | 0.06 |
| Boom length (mm) | 2000 |
| Rod length (mm) | 1050 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo D1.2 |
| Rated power (kw/rpm) | 14.4/2200 |
| Maximum torque (N.m) | 65.6/1600 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.1 |
| Ground specific pressure (Kpa) | 33.1 |
| Rotation speed (rpm) | 10 |
| Travel speed (km/h) | 3.9 |
| Maximum flow of main pump (l/min) | 64.4 |
| Fuel Tank (L) | 49 |
| Engine Oil changes (L) | 3.3 |
| Coolant (L) | 4 |
| Hydraulic System (L) | 37 |
| Total transport length (mm) | 4000 |
| Total transport width (mm) | 1500 |
| Total transport height (mm) | 2440 |
| Full cab height (mm) | 2440 |
| Counterweight ground clearance (mm) | 570 |
| Minimum ground clearance (mm) | 280 |
| Back end turning radius (mm) | 750 |
| Track gauge (mm) | 1250 |
| Track plate width (mm) | 250 |
| Track ground length (mm) | 1440 |
| Maximum digging depth (mm) | 2380 |
| Maximum excavation height (mm) | 3950 |
| Maximum unloading height (mm) | 2840 |
| Maximum vertical digging depth (mm) | 1820 |
| Maximum excavation radius of stop surface (mm) | 4330 |
