Product Description
With a working weight of 3,336.2 kg and a bucket capacity of 0.08 m³, this 2014 Volvo ECR38 excavator is ideally suited for a range of site tasks, from digging and grading to demolition. Located in 浙江绍兴, it features a robust Volvo D1.6 engine, delivering 20.6 kW at 2,200 rpm, ensuring reliable performance.
- Equipped with a backhoe bucket, providing a digging force of 2932 kN and a rod digging force of 1953 kN.
- Boasts a maximum digging depth of 2740 mm and an excavation height of 4430 mm, making it versatile for various construction needs.
- Travel speed of 3.9 km/h and a compact design with a total transport length of 4420 mm, width of 1620 mm, and height of 2440 mm, enhancing maneuverability on-site.
- Ready for immediate deployment, this machine is a practical choice for contractors looking to enhance productivity and efficiency.
| Specifications | Value |
|---|---|
| No. | 1000132 |
| Tonnage (tons) | 3 |
| Working weight (kg) | 3336.2 |
| Bucket capacity (m³) | 0.08 |
| Boom length (mm) | 2300 |
| Rod length (mm) | 1250 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo Volvo D1.6 |
| Rated power (kw/rpm) | 20.6/2200 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.6 L |
| Ground specific pressure (Kpa) | 30.3 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 2932 |
| Rod digging force (kN) | 1953 |
| Travel speed (km/h) | 3.9 |
| Maximum flow of main pump (l/min) | 94.3 |
| Fuel Tank (L) | 49 |
| Engine Oil changes (L) | 7 |
| Coolant (L) | 5 |
| Hydraulic System (L) | 48 |
| Total transport length (mm) | 4420 |
| Total transport width (mm) | 1620 |
| Total transport height (mm) | 2440 |
| Full cab height (mm) | 2440 |
| Counterweight ground clearance (mm) | 580 |
| Minimum ground clearance (mm) | 290 |
| Back end turning radius (mm) | 810 |
| Track gauge (mm) | 1320 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1600 |
| Maximum digging depth (mm) | 2740 |
| Maximum excavation height (mm) | 4430 |
| Maximum unloading height (mm) | 3190 |
| Maximum vertical digging depth (mm) | 2540 |
| Maximum excavation radius of stop surface (mm) | 4810 |
